To configure the Intel RAID Controller SRCU32 Service double click on the Intel RAID Controller
SRCU32 Service icon. See Figure 108.
The Poll-Interval determines the time between two message acquisitions of the Intel RAID
Controller SRCU32 Service.
Under Workstation you can add workstations that receive broadcast messages from the Intel
RAID Controller SRCU32.
In the device driver section you can add or remove parameters for the RAIDSRC.SYS driver
(for example, reserve parameters for raw devices).
In the IOCTLSrv property sheet you can add / remove users which have remote access to the Intel
RAID Controller SRCU32 via StorCon+. Passwords are encrypted. See Figure 109.
166
Figure 108. RAID Configuration Services
Intel RAID Controller SRCU32 User's Guide
