F P C
RONT ANEL ONTROLS
B-DISP OFF Switch
Pressing this button causes the Sub band (VFO-B)
frequency to be blanked out, for local rag-chews or
other occasions when the additional display informa-
tion is not needed. When this function is activated,
the LED inside the button will glow green.
MCH/GRP Switch
MCH Switch
Pressing this button momentarily allows you to select
the memory channel using the [ CLAR/VFO-B ] knob.
GRP Switch
Pressing and holding in this button for 2 seconds al-
lows you to select the memory group using the
[ CLAR/VFO-B ] knob.
CLAR/VFO-B Knob
Depending on the status of the [ A/B ] switch (#
described later), the [ CLAR/VFO-B ] knob is used
for functions associated with the Main (VFO-A) or
Sub (VFO-B) frequency control registers.
FAST/RX Switch
FAST Switch
When the [ A/B ] switch (#
ange lamp to the right of the [ CLAR/VFO-B ] knob
lights up, the [ CLAR/VFO-B ] knob (#
controlling the Sub (VFO-B) frequency; pressing the
[ FAST/RX ] switch will change the tuning step of the
[ CLAR/VFO-B ] knob to 100 Hz.
RX Switch
When the [ CLAR ] switch (#
imbedded LED is illuminated), pressing the [ FAST/
RX ] switch applies the programmed Clarifier offset
to the Main (VFO-A) receive frequency. Press the
[ FAST/RX ] switch once more to return the Main re-
ceiver to the frequency shown on the main frequency
display field; the Clarifier offset will still be present,
Page 34
,
) is pushed, and the Or-
) will be
) is pressed (and its
though, in case you want to use it again. To cancel the
Clarifier offset, press the [ B.MODE/CLEAR ] switch
(see details in # below).
BAND/MHz / TX Switch
BAND/MHz
When the [ A/B ] switch (#
ange lamp to the right of the [ CLAR/VFO-B ] knob
lights up, pressing the [ BAND/MHz ] switch allows
you to rotate this knob for selection of the Amateur
band to be used for the Sub band (VFO-B).
TX Switch
When the [ CLAR ] switch (#
imbedded LED is illuminated), pressing the [ BAND/
MHz/TX ] switch applies the programmed Clarifier
offset to the Main (VFO-A) transmit frequency. Press
the [ FAST/RX ] switch once more to return the trans-
mitter to the Main (VFO-A) frequency shown on the
main frequency display field; the Clarifier offset will
still be present, though, in case you want to use it
again. To cancel the Clarifier offset, press the
[ B.MODE/CLEAR ] switch (see details in #
low).
B.MODE/CLEAR Switch
B.MODE Switch
When the [ A/B ] switch (#
ange lamp to the right of the [ CLAR/VFO-B ] knob
lights up, pressing the [ B.MODE/CLEAR ] switch al-
lows you to rotate this knob for selection of the oper-
ating mode to be used on the Sub band (VFO-B).
CLEAR Switch
When the [ CLAR ] switch (#
imbedded LED is illuminated), pressing the
[ B.MODE/CLEAR ] switch clears out any frequency
offset you have programmed into the Clarifier regis-
ter (thereby setting the offset to "Zero").
FT 9000D O
DX
) is pressed, and the Or-
) is pressed (and its
be-
) is pressed, and the Or-
) is pressed (and its
