013. TFT COLOR
Function: Selects the TFT color.
Available Values: COOL BLUE/CONTRAST BLUE/
FLASH WHITE/CONTRAST UMBER/UMBER
Default Setting:
Unmber Display Color: UMBER
Light Blue Display Color: COOL BLUE
014. DIMMER-METER
Function: Setting of the meter brightness level when
"DIM" is selected.
Available Values: 0 ~ 15
Default Setting: 4
015. DIMMER-VFD
Function: Setting of the frequency and TFT display
brightness level when "DIM" is selected.
Available Values: 0 ~ 15
Default Setting: 8
016. BAR DISPLAY SELECT
Function: Selects one of three parameters to be
viewed on the Tuning Offset Indicator.
Available Values: CLAR/CW TUNE/VRF-μTUNE/
NOTCH
Default Setting: CW TUNE
CLAR: Displays relative clarifier offset.
CW TUNE: Displays relative tuning offset between
the incoming signal and transmitted
frequency.
VRF-μTUNE: Displays the peak position of the VRF
or μTUNE filter.
While you rotate the [ NOTCH ] knob,
NOTCH:
the center frequency of the IF NOTCH
feature will be indicated.
017. ROTATOR START UP
Function: Selects the starting point of your
controller's indicator needle.
Available Values: 0/90/180/270º
Default Setting: 0º
018. ROTATOR OFFSET ADJ
Function: Adjusts the indicator needle precisely to
the starting point set in menu selection 017.
Available Values: –30 - 0
Default Setting: 0
Page 146
DISPLAY G
ROUP
019. RIGHT TX METER
Function: Selects the Sub meter function
Available Values: ALC/VDD
Default Setting: ALC
ALC: Indicates incoming signal strength on the Bub
band (VFO-B) while receiving, and indicates
the ALC (Automatic Level Control) operating
range while transmitting.
VDD: Indicates the Vdd (final amplifier drain voltage)
at all times.
020. QMB MARKER
Function: Enables/Disable the QMB Maker (White
arrow " ") to display on the Spectrum Band Scope.
Available Values: ENABLE/DISABLE
Default Setting: ENABLE
021. MY SCREEN
Function: Programs a TFT operation page to be
s k i p p e d w h i l e s e l e c t i n g b a n d s u s i n g t h e
[ DISP ( DISPLAY )] key.
Available Values: MAP / RF SCOPE / AF SCOPE /
LOGBOOK / SWR / ROTATOR / MCH LIST
To program the "page" to be skipped, rotate the
CLAR/VFO-B knob to recall the "page" to be skipped,
then press the [ ENT ] key to change this setting to
"ON." Repeat the same procedures to cancel the set-
ting (skipped "off").
022. LEVEL INDICATOR
Function: Enables/Disables the Sub band (VFO-B)
frequency display to show each frequency or value
while each of the enabled knob is turned.
Available Values: PITCH / SPEED / CONTOUR /
NOTCH / DNR / CW DELAY / VOX DEALAY / RF
PWR / MIC GAIN / PROC
To disable the "function," rotate the [ CLAR/VFO-B ]
knob to recall the "function" to be disabled, then press
the [ ENT ] key to change this setting to "OFF." Re-
peat the same procedures to enable a function (set-
ting it to "ON").
023. APF INDICATOR
Function: Permits setting the blinking pattern of the
CONT LED when the APF feature is activated.
Available Values: STEADY ON / BLINKING 1sec /
BLINKING 2sec / BLINKING 3sec / BLINKING 4sec
/ BLINKING 5sec / BLINKING 7sec / BLINKING
10sec / BLINKING 20sec / BLINKING 30sec / BLINK-
ING 60sec
Default Setting: BLINKING 4sec
STEADY ON:
BLINKING 1sec ~ 60sec: The glow of the CONT
Continuous glow of the
CONT LED.
LED will turn off briefly at
the set interval.
