TUNING G
139. DIAL STEP
Function: Setting of the Tuning Knob's tuning speed
on the SSB, CW, and AM modes.
Available Values: 1 / 5 / 10 Hz
Default Setting: 10 Hz
140. DIAL CW FINE
Function: Setting of the Tuning Knob's tuning speed
in the CW mode.
Available Values: ENABLE/DISABLE
Default Setting: DISABLE
ENABLE :Tuning in 1 Hz steps on the CW mode.
DISABLE:Tuning according to the steps determined
via menu item 139:
141. 1MHz/100kHz SELECT
Function: Selects the tuning steps for the [ CLAR/
VFO-B ] knob when the [ BAND/MHz ] button is
pressed.
Available Values: 1 MHz/100 kHz
Default Setting: 1 MHz
142. AM CH STEP
Function: Selects the tuning steps for the
microphone's [ UP ] / [ DWN ] keys in the AM mode.
Available Values: 2.5 / 5 / 9 / 10 / 12.5 kHz
Default Setting: 5 kHz
143. FM CH STEP
Function: Selects the tuning steps for the
microphone's [ UP ] / [ DWN ] keys in the FM mode.
Available Values: 5 / 6.25 / 10 / 12.5 / 20 / 25 kHz
Default Setting: 5 kHz
144. FM DIAL STEP
Function: Setting of the Main Tuning Knob's tuning
speed in the FM mode.
Available Values: 10/100 Hz
Default Setting: 100 Hz
145. MY BAND
Function: Programs a band to be skipped while se-
lecting bands using the [ CLAR/VFO-B ] knob.
Available Values: 1.8 ~ 50/GEN/TRV
To program the band to be skipped, rotate the [ CLAR/
VFO-B ] knob to recall the band to be skipped while
selecting bands via the [ CLAR/VFO-B ] knob, then
press the [ ENT ] key to change this setting to "ON."
Repeat the same procedures to cancel the setting
(skipped "off").
FT 9000D O
DX PERATION
ROUP
DIAL STEP DIAL STEP DIAL STEP DIAL STEP DIAL STEP .
M
ANUAL
TX AUDIO G
146. F-PRMTRC EQ1-FREQ
Function: Selects the center frequency of the lower
range for the front panel's parametric microphone
equalizer.
Available Values: OFF/100 ~ 700 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
100 ~ 700: You may adjust the equalizer gain and
Q-factor at this selected audio frequency
via menu items 147:
LEVEL LEVEL LEVEL LEVEL LEVEL and 148:
147. F-PRMTRC EQ1-LEVEL
Function: Adjusts the equalizer gain of the low range
of the front panel's parametric microphone equalizer.
Available Values: –10 ~ +10
Default Setting: +5
148. F-PRMTRC EQ1-BWTH
Function: Adjusts the Q-factor of the low range of
the front panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
149. F-PRMTRC EQ2-FREQ
Function: Selects the center frequency of the middle
range for the front panel's parametric microphone
equalizer.
Available Values: OFF/700 ~ 1500 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
700 ~ 1500: You may adjust the equalizer gain and
Q-factor at this selected audio fre-
quency via menu items 150:
EQ2-LEVEL EQ2-LEVEL EQ2-LEVEL and 151:
EQ2-LEVEL EQ2-LEVEL
BWTH BWTH BWTH BWTH BWTH .
150. F-PRMTRC EQ2-LEVEL
Function: Adjusts the equalizer gain of the middle
range of the front panel's parametric microphone
equalizer.
Available Values: –20 ~ +10
Default Setting: +5
151. F-PRMTRC EQ2-BWTH
Function: Adjusts the Q-factor of the middle range
of the front panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
M M
ENU ODE
ROUP
F-PRMTRC EQ1- F-PRMTRC EQ1- F-PRMTRC EQ1- F-PRMTRC EQ1- F-PRMTRC EQ1-
F-PRMTRC EQ1-BWTH F-PRMTRC EQ1-BWTH F-PRMTRC EQ1-BWTH F-PRMTRC EQ1-BWTH F-PRMTRC EQ1-BWTH .
F-PRMTRC F-PRMTRC
F-PRMTRC F-PRMTRC F-PRMTRC
F-PRMTRC EQ2- F-PRMTRC EQ2- F-PRMTRC EQ2-
F-PRMTRC EQ2- F-PRMTRC EQ2-
