MODE-CW G
058. CW FREQ DISPLAY
Function: Frequency Display Format for the CW
mode.
Available Values: DIRECT FREQ/PITCH OFFSET
Default Setting: PITCH OFFSET
DIRECT FREQ: Displays the receiver carrier fre-
quency, without any offset added.
When changing modes between
SSB and CW, the frequency dis-
play remains constant.
PITCH OFFSET: This frequency display reflects the
added BFO offset.
059. PC KEYING
Function: Enables/disables CW keying from the
"PTT" terminal (pin 3) on the rear panel's PACKET
jack while operating on the CW mode.
Available Values: DISABLE/ENABLE
Default Setting: DISABLE
060. QSK
Function: Selects the time delay between when the
PTT is keyed and the carrier is transmitted during
QSK operation when using the internal keyer.
Available Values: 15/20/25/30 msec
Default Setting: 15 msec
FT 9000D O
DX PERATION
ROUP
M
ANUAL
MODE-DAT G
061. DATA IN SELECT
Function: Selects the data input to be used on the
PKT mode.
Available Values: DATA/PC
Default Setting: DATA
DATA:Uses the data input line which is connected to
the rear panel's PACKET jack while using the
PKT mode.
PC: Uses the data input line which is connected to
the rear panel's AUDIO IN jack while using
the PKT mode.
062. DATA GAIN
Function: Sets the data input level from the TNC to
the AFSK modulator.
Available Values: 0 ~ 255
Default Setting: 128
063. DATA OUT
Function: Selects the receiver to be connected to
the data output port (pin 4) of the PACKET jack.
Available Values: VFO-a/VFO-b
Default Setting: VFO-a
064. DATA VOX DELAY
Function: Adjusts the "VOX" delay (receiver recov-
ery) time on the PKT mode.
Available Values: 30 ~ 3000 msec
Default Setting: 300 msec
065. DATA VOX GAIN
Function: Adjusts the "VOX" gain on the PKT mode.
Available Values: 0 ~ 255
Default Setting: 128
M M
ENU ODE
ROUP
