RX DSP G
114. SUB-SSB-SHAPE
Function: Selects the passband characteristics of
the Sub band (VFO-B) DSP filter for the SSB mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
115. SUB-SSB-SLOPE
Function: Selects the shape factor of the Sub band
(VFO-B) DSP filter for the SSB mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
116. SUB-SSB-NARROW
Function: Selects the passband of the Sain band
(VFO-B) DSP filter for the "narrow" SSB mode.
Available Values: 200/400/600/850/1100/1350/
1500/1650/1800/1950/2100/2250 Hz
Default Setting: 1800 Hz
SHARP
MEDIUM
WIDE
F P
ILTER
SHARP
F
ILTER
FT 9000D O
DX PERATION
ROUP
ASSBAND
SOFT
S
HAPE
M
ANUAL
SCOPE G
117. MAIN FIX 1.8 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 160 m amateur band.
Available Values: 1800 - 1999 kHz (1 kHz steps)
Default Setting: 1800 kHz
118. MAIN FIX 3.5 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 80 m amateur band.
Available Values: 3500 - 3999 kHz (1 kHz steps)
Default Setting: 3500 kHz
119. MAIN FIX 5.0 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 60 m amateur band.
Available Values: 5250 - 5499 kHz (1 kHz steps)
Default Setting: 5250 kHz
120. MAIN FIX 7.0 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 40 m amateur band.
Available Values: 7000 - 7299 kHz (1 kHz steps)
Default Setting: 7000 kHz
121. MAIN FIX 10 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
30 m amateur band.
Available Values: 10100 - 10149 kHz (1 kHz steps)
Default Setting: 10100 kHz
122. MAIN FIX 14 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 20 m amateur band.
Available Values: 14000 - 14349 kHz (1 kHz steps)
Default Setting: 14000 kHz
123. MAIN FIX 18 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 17 m amateur band.
Available Values: 18000 - 18199 kHz (1 kHz steps)
Default Setting: 18068 kHz
124. MAIN FIX 21 MHz
Function: Selects the scan start frequency of the
FIX mode Spectrum Scope while monitoring on the
Main band (VFO-A) 15 m amateur band.
Available Values: 21000 - 21449 kHz (1 kHz steps)
Default Setting: 21000 kHz
M M
ENU ODE
ROUP
