Yaesu FTDX9000D - DATA MANAGEMENT Operation Manual page 162

M M
ENU ODE
152. F-PRMTRC EQ3-FREQ
Function: Selects the center frequency of the high
range for the front panel's parametric microphone
equalizer.
Available Values: OFF/1500 ~ 3200 Hz (100 Hz/
step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are
set to factory defaults (flat).
1500 ~ 3200: You may adjust the equalizer gain and
Q-factor in this selected audio fre-
quency via menu items 153:
PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
153. F-PRMTRC EQ3-LEVEL
Function: Adjusts the equalizer gain of the high
range of the front panel's parametric microphone
equalizer.
Available Values: –20 ~ +10
Default Setting: +5
154. F-PRMTRC EQ3-BWTH
Function: Adjusts the Q-factor of the high range of
the front panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
155. R-PRMTRC EQ1-FREQ
Function: Selects the center frequency of the low
range for the rear panel's parametric microphone
equalizer.
Available Values: OFF/100 ~ 700 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
100 ~ 700: You may adjust the equalizer gain and
Q-factor in this selected audio frequency
via menu items 156:
LEVEL LEVEL and 157:
LEVEL LEVEL LEVEL
156. R-PRMTRC EQ1-LEVEL
Function: Adjusts the equalizer gain of the low range
of the rear panel's parametric microphone equalizer.
Available Values: –20 ~ +10
Default Setting: +5
157. R-PRMTRC EQ1-BWTH
Function: Adjusts the Q-factor of the low range of
the rear panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
Page 160
TX AUDIO G
F- F- F- F- F-
and 154:
F- F- F- F- F-
.
R-PRMTRC EQ1- R-PRMTRC EQ1- R-PRMTRC EQ1- R-PRMTRC EQ1- R-PRMTRC EQ1-
R-PRMTRC EQ1-BWTH R-PRMTRC EQ1-BWTH .
R-PRMTRC EQ1-BWTH R-PRMTRC EQ1-BWTH R-PRMTRC EQ1-BWTH
ROUP
158. R-PRMTRC EQ2-FREQ
Function: Selects the center frequency of the middle
range for the rear panel's parametric microphone
equalizer.
Available Values: OFF/700 ~ 1500 Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
700 ~ 1500: You may adjust the equalizer gain and
Q-factor at this selected audio fre-
quency via menu items 159:
PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL
PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH
159. R-PRMTRC EQ2-LEVEL
Function: Adjusts the equalizer gain of the middle
range of the rear panel's parametric microphone
equalizer.
Available Values: –20 ~ +10
Default Setting: +5
160. R-PRMTRC EQ2-BWTH
Function: Adjusts the Q-factor of the middle range
of the rear panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
161. R-PRMTRC EQ3-FREQ
Function: Selects the center frequency of the high
range for the rear panel's parametric microphone
equalizer.
Available Values: OFF/1500 ~ 3200 Hz (100 Hz/
step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
1500 ~ 3200:You may adjust the equalizer gain and
Q-factor at this selected audio fre-
quency via menu items 162:
PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL
PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
162. R-PRMTRC EQ3-LEVEL
Function: Adjusts the equalizer gain of the high
range of the rear panel's parametric microphone
equalizer.
Available Values: –20 ~ +10
Default Setting: +5
163. R-PRMTRC EQ3-BWTH
Function: Adjusts the Q-factor of the high range of
the rear panel's parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
FT 9000D O
DX
R- R- R- R- R-
and 160: R- R- R- R- R-
.
R- R- R- R- R-
and 163: R- R- R- R- R-
.
M
PERATION ANUAL
