MODE-FM G
066. FM MIC GAIN
Function: Sets the microphone gain for the FM mode.
Available Values: MCVR/0 ~ 255 (FIX)
Default Setting: 128
When this menu is set to "MCVR," you may adjust
the microphone gain using the front panel's MIC knob.
067. FM MIC SELECT
Function: Selects the microphone to be used on the
FM mode.
Available Values: FRONT/REAR/DATA/PC
Default Setting: FRONT
FRONT: Selects the microphone connected to the
front panel's MIC jack while using the FM
mode.
REAR: Selects the microphone connected to the
rear panel's MIC jack while using the FM
mode.
DATA: Selects the microphone connected to pin 1
of the PACKET Jack while using the FM
mode.
PC: Selects the microphone connected to the
rear panel's AUDIO IN 3.5-mm jack while
using the FM mode.
068. RPT SHIFT ( 28MHz )
Function: Sets the magnitude of the repeater shift
on the 28 MHz band.
Available Values: 0 ~ 1000 kHz
Default Setting: 100 kHz
069. RPT SHIFT ( 50MHz )
Function: Sets the magnitude of the repeater shift
on the 50 MHz band.
Available Values: 0 ~ 4000 kHz
Default Setting: 1000 kHz
Page 152
ROUP
070. PKT DISP
Function: Sets the packet frequency display offset.
Available Values: –3000 ~ +3000 Hz (10 Hz/step)
Default Setting: 0 Hz
071. PKT GAIN
Function: Adjusts the audio input level from the TNC
to the AFSK modulator.
Available Values: 0 ~ 255
Default Setting: 128
072. PKT SHIFT
Function: Sets the carrier point during the SSB
Packet operation
Available Values: –3000 ~ +3000 Hz (10 Hz/step)
Default Setting: +1000 Hz (Typical center frequency
for PSK31, etc.)
