CW C
ONVENIENCE

Contest Memory Keyer

The supplied FH-2 Remote Control Keypad may be used as a control keypad for the automatic sending of CW messages
(as you might do in a contest).
Two techniques for message storage are available: you may either send the desired message contents using your keyer
paddle ("Message Memory"), or you may input the text characters using the TFT ("Text Memory").
See page 15 for details regarding interconnection of the FH-2.

Message Memory

Five memory channels capable of retaining 50 characters total are provided (using the PARIS standard for characters and
word length).
Example : CQ CQ CQ DE W6DXC K (14 characters)
− • − • −− • − − • − • −− • −
(C) (Q) (C) (Q)
Storing a Message into Memory
1. Press the [ MNU ] key to enter the Menu mode.
2. Rotate the [ Main Tuning Dial ] knob to select the
CW Memory Register into which you wish to store
the message; for now, we are just selecting the mes-
sage entry technique (Keyer entry or Text entry).
FH-2SET 027 CW MEMORY 1
FH-2SET 028 CW MEMORY 2
FH-2SET 029 CW MEMORY 3
FH-2SET 030 CW MEMORY 4
FH-2SET 031 CW MEMORY 5
3. Rotate the [ CLAR/VFO-B ] knob to set the selected
Memory Register to "MESSAGE." If you want to use
your keyer paddle for message entry on all memo-
ries, set all five Menu items (#027 ~ 031) to "MES-
SAGE".
4. Press and hold in the [ MNU ] key to save the new
settings and exit.
Page 114
F
EATURES
C M
ONTEST EMORY
− • − • −− • −
(C) (Q)
[ MAIN ] tuning dial
K
EYER
− •• • • −− − •••• − •• − •• − − • − •
(D) (E) (W) (6) (D) (X)
T T T T T
ERMINOL ERMINOLOGY ERMINOL ERMINOL ERMINOL
PARIS Word Length
By convention in the Amateur industry (utilized
by ARRL and others), the length of one "word" of
CW is defined as the length of the Morse Code
characters spelling the word "PARIS." This char-
acter (dot/dash/space) length is used for the rigor-
ous definition of code speed in "words per minute".
FT 9000D O
DX
− • −
(C) (K)
[ MNU ] key
[ CLAR/VFO-B ] knob
OGY OGY OGY OGY
M
PERATION ANUAL
