MODE-RTY G
073. POLARITY-R
Function: Selects normal or reverse Mark/Space po-
larity for RTTY receive operation.
Available Values: NOR/REV
Default Setting: NOR
074. POLARITY-T
Function: Selects normal or reverse Mark/Space po-
larity for RTTY transmit operation.
Available Values: NOR/REV
Default Setting: NOR
075. RTTY SHIFT
Function: Selects the frequency shift for the FSK
RTTY operation.
Available Values:170/200/425/850 Hz
Default Setting: 170 Hz
076. RTTY TONE
Function: Selects the mark tone for RTTY opera-
tion.
Available Values: 1275/2125 Hz
Default Setting: 2125 Hz
FT 9000D O
DX PERATION
ROUP
M
ANUAL
MODE-SSB G
077. SSB MIC SELECT
Function: Selects the microphone to be used on the
SSB mode.
Available Values: FRONT/REAR/DATA/PC
Default Setting: FRONT
FRONT: Selects the microphone connected to the
front panel's MIC jack while using the SSB
modes.
REAR: Selects the microphone connected to the
rear panel's MIC jack while using the SSB
modes.
DATA: Selects the microphone connected to pin 1
of the PACKET Jack while using the SSB
modes.
PC: Selects the microphone connected to the
rear panel's AUDIO IN 3.5-mm jack while
using the SSB modes.
078. SSB-TX-BPF
Function: Selects the audio passband of the En-
hanced DSP modulator on the SSB mode.
Available Values: 50-3000(Hz)/100-2900(Hz)/
200-2800(Hz)/300-2700(Hz)/400-2600(Hz)/3000WB
Default Setting: 300-2700 Hz
079. LSB RX-CARRIER
Function: Adjusts the receiver carrier point for LSB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
080. LSB TX-CARRIER
Function: Adjusts the transmitter carrier point for LSB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
081. USB RX-CARRIER
Function: Adjusts the receiver carrier point for USB
mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
082. USB TX-CARRIER
Function: Adjusts the transmitter carrier point for
USB mode.
Available Values: –200 Hz ~ +200 Hz (10 Hz steps)
Default Setting: 0 Hz
M M
ENU ODE
ROUP
Page 153
