102. MAIN-SSB-SHAPE
Function: Selects the passband characteristics of
the Main band (VFO-A) DSP filter for the SSB mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
103. MAIN-SSB-SLOPE
Function: Selects the shape factor of the Main band
(VFO-A) DSP filter for the SSB mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
104. MAIN-SSB-NARROW
Function: Selects the passband of the Main band
(VFO-A) DSP filter for the "narrow" SSB mode.
Available Values: 200/400/600/850/1100/1350/
1500/1650/1800/1950/2100/2250 Hz
Default Setting: 1800 Hz
105. SUB-CW-SHAPE
Function: Selects the passband characteristics of
the Sub band (VFO-B) DSP filter for the CW mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
106. SUB-CW-SLOPE
Function: Selects the shape factor of the Sub band
(VFO-B) DSP filter for the CW mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
107. SUB-CW-NARROW
Function: Selects the passband of the Sub band
(VFO-B) DSP filter for the CW "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
Page 156
RX DSP G
ROUP
108. SUB-PSK-SHAPE
Function: Selects the passband characteristics of
the Sub band (VFO-B) DSP filter for the PSK mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
109. SUB-PSK-SLOPE
Function: Selects the shape factor of the Sub band
(VFO-B) DSP filter for the PSK mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
110. SUB-PSK-NARROW
Function: Selects the passband of the Sub band
(VFO-B) DSP filter for the PSK "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
111. SUB-RTTY-SHAPE
Function: Selects the passband characteristics of
the Sub band (VFO-B) DSP filter for the RTTY mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
112. SUB-RTTY-SLOPE
Function: Selects the shape factor of the Sub band
(VFO-B) DSP filter for the RTTY mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
113. SUB-RTTY-NARROW
Function: Selects the passband of the Sub band
(VFO-B) DSP filter for the RTTY "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
