  • Page 1 Operation Manual...

  • Page 3: General Description

    We wish to take this opportunity to thank you for your purchase of the FT 9000D Transceiver! The FT 9000D is the culmination of a four-year design project. But it also is the product of our company’s fifty years of engineering, design, and manufacturing know how.

  • Page 4: Table Of Contents

    General Description ........... 1 More Frequency Navigation Techniques .......... 57 About This Manual................1 ANTENNA SELECTION ..............58 Conventions Used in This Manual ............1 Changing the Speaker Output Configuration ........59 About the TFT Display ................ 1 Receiver Operation (Front End Block Diagram) ......
  • Page 5 CW Mode Operation ........100 Memory Operation .......... 115 Setup for Straight Key (and Straight Key emulation) Operation ..100 Memory Storage ................115 Using the Built-in Electronic Keyer ..........101 Memory Channel Recall ..............115 Full Break-in (QSK) Operation ............101 Checking a Memory Channel’s Status ........

  • Page 6: Before You Begin

    Before You Begin. . . 1. Connecting AC Power There are two power switches on this transceiver, one each on the rear and front panels. If the rear panel’s Power switch is not turned on, the front panel Power switch will not function. Ì...

  • Page 7: Connecting And Selecting The Microphone

    Before You Begin. . . 4. Connecting and Selecting the Microphone The FT 9000D comes equipped with two microphone connectors: the front panel includes a “Cannon” (XLR) three-pin connector, while the rear panel provides an eight-pin (round) connector. As shipped from the factory, the front panel XLR connector is engaged for operation, and the rear panel 8-pin microphone jack is not connected.

  • Page 8: Adjusting The Main Dial Torque

    Before You Begin. . . 6. Adjusting the Main Dial Torque The torque (drag) of the Main Tuning Dial may be adjusted according to your preferences. Simply hold down the rear skirt of the knob, and while holding it in place rotate the Main Dial itself to the right to reduce the drag, or to the left to increase the drag.

  • Page 9: Resetting The Microprocessor

    Before You Begin. . . 8. Resetting the Microprocessor Ë Resetting Memories (Only) Use this procedure to reset (clear out) the Memory channels previously stored, without affecting any configuration changes you may have made to the Menu settings. 1. Press the front panel’s POWER switch to turn the transceiver off.

  • Page 10: Features

    Ultra-strong Receiver Front End YAESU’s outstanding RF-stage filtering establishes a clean performance that allows the rest of the receiver to perform at a high level. By reducing the ingress of energy from very strong sources like Shortwave Broadcast, local AM/FM/TV stations, and other signal sources, the overall purity of the spectrum delivered to the RF Amplifier first mixer, and subsequent stages is maintained, and the system Blocking Dynamic Range is also enhanced.
  • Page 11 VRF (Variable RF Filter) Preselector Filter (Page 66) On the 18 MHz and higher Amateur bands, and on 1.8 - 50 MHz on the Sub (VFO-B) band, Yaesu’s robust VRF (Variable RF Filter) preselector provides a relay-selected RF selectivity much tighter than that afforded by traditional bandpass filter networks. Sealed relays select heavy-duty inductors and capacitors, providing a tracking RF filter that protects the RF amplifier and following stages from strong out-of-band energy.

  • Page 12: Accessories

    FH-2 CF Card AC Power Cord Plugs Remote Control Keypad (64 MB: Q9000838) Microphone Extend Cable (8 Pin Modular) H Operating Manual 2: AC Power Cord H Warranty Card USA: T9017882 Europe: T9013285 Australia: T9013283A T9013285 2: This microphone cable (T9101549) is for use with the optional MD-200 , MD-100 , or MH-31...

  • Page 13: Options

    MD-200 Ultra-High-Fidelity Desk-Top Microphone Lightweight Stereo Headphones MD-200 YH-77STA Desk-Top Microphone MD-100 External Speaker with Dual Speakers and Audio Filter Linear Amplifier / AC Power Supply SP-9000 VL-1000 / VP-1000 9000D O Page 11...

  • Page 14: Installation And Interconnections

    The FT 9000D is designed for use with any antenna system providing a 50 Ohm resistive impedance at the desired operating frequency. While minor excursions from the 50-Ohm specification are of no consequence, the transceiver’s Automatic Antenna Tuner may not be able to reduce the impedance mismatch to an acceptable value if the Standing Wave Ratio (SWR) present at the Antenna jack is greater than 3:1.

  • Page 15: Grounding

    The FT 9000D HF transceiver, like any other HF communications apparatus, requires an effective ground system for maximum electrical safety and best communications effectiveness. A good ground system can contribute to station effi- ciency in a number of ways: Ì It can minimize the possibility of electrical shock to the operator. Ì...

  • Page 16: Connection Of Antenna And Power Cables

    Please follow the outline in the illustration regarding the proper connection of antenna coaxial cables, as well as the AC power cable. Use a short, thick, braided cable to connect your sta- tion equipment to the bur- ied ground rod (or alterna- tive earth ground system).

  • Page 17: Remote Control Keypad

    FH-2 R This transceiver was shipped from the factory in configuration for a microphone input via the Front Panel XLR connector. To use the Rear Panel microphone with an 8-pin round connector, please change the microphone set up via the Menu. 1.

  • Page 18: Key, Keyer, And Computer-Driven Keying Interconnections

    K , K The FT 9000D includes a host of features for the CW operator, the functions of which will be detailed in the “Operation” section later. Besides the built-in Electronic Keyer, two key jacks are provided, one each on the front and rear panels, for convenient connection to keying devices.

  • Page 19: Vl-1000 Linear Amplifier Interconnections

    VL-1000 L Be sure that both the FT 9000D and VL-1000 are turned off, then follow the installation recommendations contained in the illustration. On the rear panel of the VL-1000, please set the “ATT” switch to the “ON” position. The 200-Watt power output from the 9000D is far in excess of what is required to drive the VL-1000 to its full rated output.

  • Page 20: Interfacing To Other Linear Amplifiers

    ANTENNA CABLE 50 （ Ω） RF OUT RF IN FUSE GND RELAY Note G The TX/RX switching in the linear amplifier is controlled by switching components in the transceiver. The relay circuit of the FT 9000D used for this switching is capable of switching AC voltage of 100 Volts at up to 300 mA, or DC voltages or 60 V at 200 mA or 30 V at up to 1 Amp.

  • Page 21: Plug/Connector Pinout Diagrams

    BAND DATA1 BAND DATA2 +13V EXT ALC SERIAL OUT TX GND TX GND SERIAL IN BAND DATA A BAND DATA B BAND DATA C TXINH BAND DATA D FSET LINEAR (as viewed from rear panel) (as viewed from rear panel) (as viewed from rear panel) PACKET ROTATOR...

  • Page 22: Front Panel Controls

    PHONES Jack MOX Switch A 1/4-inch, 3-contact jack accepts either monaural or Pressing this button engages the PTT (Push to Talk) stereo headphones with 2- or 3-contact plugs. When a circuit, to activate the transmitter. It must be in the plug is inserted, the loudspeaker is disabled.
  • Page 23 KEY Jack ANTENNA SELECT Switches These momentary buttons select the antenna jack on This 1/4-inch, 3-contact jack accepts a CW key or the rear panel, with the selection indicated by the LED keyer paddles (for the built-in electronic keyer), or in each button.
  • Page 24 MONI PITCH Knobs METER Switch MONI Knob This control switch determines the function of the The inner MONI knob adjusts the audio level of the Main Meter during transmission. transmit RF monitor during transmission (relative to the COMP: Indicates the RF speech compressor AF GAIN control), when activated by the MONI but- level (SSB modes only).
  • Page 25 PROC Knobs KEYER Switch MIC Knob This button toggles the internal CW keyer on and off. The inner MIC knob adjusts the microphone input While activated, the LED in this button glows red. The level for (non-processed) SSB transmission. Keyer sending speed, and the CW Hang Time are ad- Advice justed via the controls described in the next section.
  • Page 26 NB Switch very strong signal within several dizen kHz is causing you problems, you may use the VRF/µ- Pressing this button activates the (analog) IF Noise T / NTCH knob to skew the tuning to one side Blanker, which may help reduce many different types of the other of your current frequency, to roll off of man-made impulse noise (but not atmospherics).
  • Page 27 NTCH Switch CONT DNR Knob This button turns the main band (VFO-A) IF notch CONT Knob filter on and off. When the IF notch filter is activated, The inner CONT knob selects the desired sub band the LED inside the button will glow red. The Notch (VFO-B) CONTOUR filter response.
  • Page 28 QMB (Quick Memory Bank) Switch MODE Switches STO (Store) Button A, B Button Pressing this button copies operating information (fre- Pressing the A or B switch will illuminate the quency, mode, bandwidth, and also repeater direction/ respective indicator imbedded within the switch, al- shift frequency and CTCSS functions on the FM mode) lowing adjustment of the operating mode on the Main into consecutive QMB Memories.
  • Page 29 SPLIT Switch Main Dial Knob Pressing this button to activates split frequency opera- This large knob adjusts the operating frequency of the tion between the main band (VFO-A), used for trans- Main (VFO-A) Band or a recalled memory. Clockwise mission and sub band (VFO-B), used for reception. The rotation of this knob increases the frequency.
  • Page 30 A B Switch A-BUSY Indicator Pressing this button momentarily exchanges the con- This LED glows green whenever the Main band (VFO- tents of the main band (VFO-A) (or a recalled memory A) receiver squelch is open. If this indicator is not channel) and the sub band (VFO-B).
  • Page 31 DUAL Indicator S-Meter (Sub Receiver) This indicator glows Green when Dual Receive is en- On receive, this meter displays signal strength of in- gaged. coming signals as received on the Sub (VFO-B) band receiver. HI SWR Indicator On transmit, this meter serves as the ALC meter. The This indicator glows Red if the directional coupler function of this meter, on transmit, can be changed to and microprocessor detect an abnormally high SWR...
  • Page 32 Advice (AF GAIN RF GAIN) below pertain to operations associated with the Sub Sections (R.FLT) through (VFO-B) band. Because their function is basically identical to that explained with respect to the Main (VFO-A) band, please see the Main (VFO-A) band discussions for detailed explanations of these controls, switches, and indicators.
  • Page 33 SQL Knobs DNR Switch (Refer to Main (VFO-A): (Refer to Main (VFO-A): NB Knob This button turns the sub band (VFO-B) Digital Noise This adjusts the Sub (VFO-B) band receiver’s IF Noise Reduction circuit on and off. When the Digital Noise Blanker level, when the Noise Blanker is engaged via Reduction is activated, the LED inside the button will the NB switch, described below.
  • Page 34 RF PWR BIAS Knobs CF Card Slot RF PWR Knob This slot accepts the supplied Compact Flash (CF) Card, This is the main RF Power output control for the which allows storage, transfer, and recall of transceiver transceiver, active in all operating modes. Clock- configuration data and operator preferences, along with wise rotation increases the power output.
  • Page 35 P.BACK Switch ACM (Adjacent Channel monitor) Switch (CW Mode) Press and hold in this button for 2 seconds to activate the recording feature of the internal Digital Voice Re- When using a narrow bandwidth, such as 300 Hz, on corder. The Voice Recorder allows you to record the the Main (VFO-A) band receiver in the CW mode, main band (VFO-A) receiver audio for the most-re- pressing the ACM switch will take over the Sub (VFO-...
  • Page 36 CLAR/VFO-B Knob Depending on the status of the A/B switch (# , described later) the CLAR/VFO-B is used for functions associated with the Main (VFO-A) or Sub (VFO-B) frequency control registers. Advice Functions Associated with Main (VFO-A) Control In the case of Main (VFO-A) control, this knob is used for Clarifier tuning, as well as Up/Down selection of the Amateur band, Memory Channels, 1 MHz tuning steps, or Memory Groups.
  • Page 37 FAST/RX Switch A/B Switch FAST Switch The A/B switch controls the determines whether When the A/B switch (# ) is pushed, and the Or- the actions of the CLAR/VFO-B knob will be ap- ange lamp to the right of the CLAR/VFO-B knob plied to the Main (VFO-A) band (“CLAR”...
  • Page 38 ( VFO-B ) This 8-pin jack accepts input from a microphone uti- RX ANT lizing a traditional YAESU HF-transceiver pinout. This type-M jack is for a separate receive-only an- REMOTE tenna. An antenna connected here can be used, by both...
  • Page 39 This 5-pin MINI-DIN Jack accepts a cable connected nal amplification. Peak signal level is 3 Vrms at 10 k- to a YAESU G-800DXA/-1000DXA/-2800DXA An- Ohms. Main band (VFO-A) receiver audio is on the tenna Rotator. You may control the antenna azimuth...

  • Page 40: Key Board

    KEY BOARD This 1/4-inch gold-plated phone jack accepts a CW Connect your keyboard (not supplied) to one of these key or keyer paddle. A 2-contact plug cannot be used jacks in accordance with your keyboard type (“USB” in this jack. Key-up voltage is +5 V, and key-down or “PS/2”) to use the Smart Memory Card for storage current is 1 mA.

  • Page 41: Frequency Display

    Main (VFO-A) Band TX/RX Indicators Multi-Panel These combination lamp-buttons select and indicate This field within the frequency display area provides the transmit/receive status of the Main (VFO-A) band. several indications, depending on the frequency con- When the green “RX” lamp is lit, the receiving fre- trol mode in use: quency is under control of the Main Tuning Knob CLAR (Clarifier)

  • Page 42: Tft Feature/Control Details

    TFT F Pressing any of these keys provides one-touch access For entering a frequency directly into the Sub (VFO- to the Amateur bands from 1.8 ~ 28 MHz. When the B) register, press this key. Then use the keys described ENT key has been pressed first, these keys then in sections (A) and (B) above for entering the digits serve as the frequency entry digits (“1”...

  • Page 43: Operation

    FH-2 O The supplied Remote Control Keypad “FH-2” can be used to control the voice memory capability for the SSB/AM/FM modes, and the contest memory keyer for the CW mode. You can also play back up to 30 seconds of incoming received audio, as well, for verification of a missed callsign or other purposes.

  • Page 44: Receiving On Amateur Bands

    Before turning on main power, please verify the following items once more. G Have you made all ground connections securely? See page 13 for details. G Do you have your antenna(s) connected to the rear-panel Antenna jack(s)? See page 14 for details. G Is your microphone (and/or key or paddle) connected? See page 15 and 16 for details.

  • Page 45: Operation

    RX switch Main (VFO-A) BAND key RX swtch Sub (VFO-B) CLAR/VFO-B knob AF GAIN knob AF GAIN knob BAND/MHz switch POWER swtch Sub (VFO-B) Main (VFO-A) Advice 1. Plug the AC cable back in, set the rear-panel Power switch to “ .” If you press the MAIN RX key (# ) when the 2.
  • Page 46 ANTENNA SELECT switch MODE key FAST switch SQL knob PITCH knob MAIN tuning dial CLAR/VFO-B knob Advice 9. Press the appropriate MODE key H Depending on the setting of the A/B switch ) to select the desired operat- ), the function of the CLAR/VFO-B knob ing mode.

  • Page 47: Operation On 60-Meter (5 Mhz) Band (U.s. Version Only)

    H It is possible to separate the frequency change over 10. Rotate the Main Tuning Dial knob to tune around the band, and begin normal operation. one dial rotation, while operating solely on the Quick Note CW mode, using the Menu items “TUNING 129 H Clockwise rotation of the Main tuning Dial in- MAIN DIAL STEP,”...

  • Page 48: Clar (Clarifier) Operation On Main (Vfo-A)

    CLAR C VFO-A The CLAR button and CLAR/VFO-B knob are used to offset either the receive, transmit, or both frequencies from their settings on the main band (VFO-A) frequency (the Clarifier does not affect the sub band (VFO-B), however). The four small numbers on the Multi Display Window show the current Clarifier offset.

  • Page 49: Lock

    LOCK You may lock the setting of the Main Tuning Dial, to prevent accidental frequency change. To lock out the Main Tuning Dial (# ), just press the LOCK switch (# ) that is located to the right of the Dial.

  • Page 50: Convenient Features

    The FT 9000D is capable of simultaneous reception, using the Main (VFO-A) and Sub (VFO-B) receivers, in what is called the Dual Receive mode. Especially useful for DX work, here is the operating procedure for Dual Receive operation. 1. While receiving on the Main (VFO-A) band, engage MAIN(VFO-A) MODE MAIN(VFO-A)
  • Page 51 The FT 9000D includes a unique capability among HF Note transceivers: the ability to operate in a full duplex envi- Full Duplex operation within the same band (e.g. both Main ronment, where by you can transmit on the Main (VFO- and Sub VFOs on 20 meters) is not possible.

  • Page 52: Using Headphones For Dual Receive

    Using Headphones for Dual Receive To take advantage of dual reception, you will want to connect stereo headphones to the PHONES jack. Like the AF GAIN control, headphone audio mixing can also be configured as desired from Menu Selection “RX AUDIO 076 HEADPHONE MIX.”...

  • Page 53: Bandwidth Diversity Reception

    Bandwidth Diversity Reception This mode involves receiving the same signal through two different bandpass filters. The frequency and mode of both the Main band (VFO-A) and Sub band (VFO-B) are the same. The main band (VFO-A) can be set up for a narrow bandpass, and the Sub band (VFO-B) for a wide bandpass, using the WIDTH knobs, resulting in a spatial perception of the channel.

  • Page 54: P.back (Audio Playback) From Main (Vfo-A) Receiver

    P.BACK A VFO-A R Once engaged by the operator, the FT 9000D begins the automatic recording of the last 30 seconds of incoming receiver audio on the Main (VFO-A) band. This capability is especially useful for confirming a callsign that may have been difficult to copy due to noise or QRM, etc.

  • Page 55: My Bands" Operation

    “M B ” O When operating on an Amateur Band on the Main (VFO-A) register, it is possible to use the BAND/MHz switch (# to engage the use of the CLAR/VFO-B knob (# ) for Amateur band selection. The “My Bands” feature allows you to select several Amateur bands, and make only those bands available for selection via the CLAR/VFO-B tuning knob.

  • Page 56: Band Stack Operation

    The FT 9000D utilizes a triple band-stack VFO selection technique, that permits you to store up to three favorite frequencies and modes onto each band's VFO register. For example, you may store one frequency each on 14 MHz CW, RTTY, and USB, then recall these VFOs by successive, momentary presses of the [14] MHz band key. Each Amateur band key may similarly have up to three frequency/mode settings applied.

  • Page 57: Dial Swap Configuration (Af/Rf Gain Controls)

    AF/RF GAIN Using the Menu, it is possible to change the RF GAIN control (for the Main (VFO-A) band) to serve as the Sub (VFO- B) AF GAIN control. In this case, the Menu Item “GENERAL 038 AF/RF DIAL SWAP” will move the Main (VFO-A) RF GAIN control function to the knob normally utilized for the Sub (VFO-B) receiver’s AF GAIN control.

  • Page 58: Custom Switch)

    C.S C An often-used Menu mode selection may be brought out to the front panel’s C.S key C.S Setup 1. Press the MNU key (# ) to engage the Menu mode; the Menu list will appear on the TFT. 2. Rotate the Main tuning dial to select the Menu item you want to be able to access via the C.S key (# 3.

  • Page 59: More Frequency Navigation Techniques

    Keyboard Frequency Entry (# Advice H In the above examples, you will notice that the trail- You may enter operating frequencies, for either the Main (VFO-A) or Sub (VFO- ing “zero” digits of the frequency were not entered. It B) bands, using the front panel band/fre- is not necessary to enter these trailing zeroes;...

  • Page 60: Antenna Selection

    Four main antenna jacks, available for both transmission and reception, are provided on the rear panel of the transceiver. What's more, a receive-only jack is provided, and the incoming signal path may also have a special after-market filter or preamplifier inserted, if desired, with one-touch access. Selection of the desired TX/RX antenna is accomplished ANTENNA SELECT switch by pressing the appropriate 1 ~ 4 Antenna Selection...

  • Page 61: Changing The Speaker Output Configuration

    An internal switch, and the menu, allow you to configure the way audio is fed to the two internal speakers (either “stereo” or “monaural” modes are available). Advice At the factory, the audio signals from both the Main and Sub receivers are combined, and the resulting monaural audio takes advantage of the combined aperture of the two speakers.

  • Page 62: Receiver Operation (Front End Block Diagram)

    On the 18 MHz and higher Amateur bands on the Main (VFO-A) re- DNR (Digital Noise Reduction) (See page 72) ceiver, and on all Amateur bands on the Sub (VFO-B) receiver, Yaesu’s powerful VRF (Variable RF Filter) preselector circuit provides excel- The DSP’s Digital Noise Reduction (DNR) feature utilizes sixteen dif-...

  • Page 63: Ipo (Intercept Point Optimization)

    IPO I Normally, the front-end FET RF amplifiers provide maximum sensitivity for weak signals. During typical conditions on lower frequencies (where strong signals and high noise are common), the RF amplifiers can be bypassed by pressing the IPO button so that the button's illumination is lit. This improves the IMD (intermodulation distortion) rejection charac- teristics of the receiver, with only a slight reduction of sensitivity.

  • Page 64: Att

    Even with the IPO function on, extremely strong local signals or high noise can still degrade reception. In such situations, you can use the ATT knob to insert 3, 6, 12, or 18-dB of RF attenuation in front of the RF amplifier. Main (VFO-A) Attenuator Setup MAIN(VFO-A) Rotate the Main (VFO-A) side’s ATT switch (#...

  • Page 65: Rf Gain (Ssb/Cw/Am Modes)

    RF G SSB/CW/AM M The RF Gain controls provide manual adjustment of the gain levels for the receiver RF and IF stages, to account for noise and/or signal strength conditions at the moment. Main (VFO-A) RF Gain Adjustment The Main (VFO-A) RF GAIN control (# ) should, initially, be rotated to the fully clockwise position.

  • Page 66: Suppression Features

    : RF F The FT 9000D includes an unmatched array of RF selectivity-enhancing features. Please study the material below carefully, so as to understand the various features complete. µ-T The µ-Tune system is an advanced preselector for the RF front end of the Main (VFO-A) receiver, providing a much narrower passband than the VRF circuit.
  • Page 67 : RF F µ-T µ-Tune and VRF: Comparisons to Fixed Bandpass Filters µ-Tune Inspection of the illustrations to the right will demonstrate the profound advantage of the µ-Tune circuit. In illustration , the gray area represents the passband of a typical fixed bandpass filter covering the 1.8 ~ 3 MHz range;...

  • Page 68: Using The Vrf (Variable Rf Front-End Filter)

    : RF F VRF V RF F The VRF system is a high-performance RF front-end preselector that has lower Q and lower insertion loss than the µ-Tune circuit. VRF provides outstanding rejection of out-of-band signals, and if low gain in your antenna system causes insertion loss to be a critical factor, you may wish to use VRF, instead of µ-Tune, on the bands below 14 MHz.

  • Page 69: Interference Rejection

    R.FLT R Narrow-band Roofing Filters of 15 kHz, 6 kHz, and 3 kHz bandwidths are provided in the first IF, right after the first mixer. These filters provide protection for the 2nd mixer, DSP, and other circuitry that follow and can dramatically improve reception on a very crowded band (during a contest, etc.).

  • Page 70: Cont (Contour) Control Operation

    CONT C The Contour filtering system provides a gentle perturbation of the IF filter passband, so as to suppress or enhance certain frequency components modestly, so as to enhance the natural-sounding received signal. Using Contour on the Main (VFO-A) Receiver MAIN(VFO-A) CONT switch 1.

  • Page 71: If Shift Operation (Ssb/Cw/Rtty/Pkt/Am Modes)

    IF SHIFT O SSB/CW/RTTY/PKT/AM M IF Shift allows you to vary the DSP filter passband higher or lower, without changing the pitch of the incoming signal, so as to reduce or eliminate interference. Because the carrier tuning frequency is not varied, there is no need to re-tune the operating frequency when eliminating the interference.

  • Page 72: (Ssb/Cw/Rtty/Pkt Modes)

    WIDTH IF DSP B SSB/CW/RTTY/PKT M The IF Width tuning system allows you to vary the width of the DSP IF passband, so as to eliminate interference. Moreover, the bandwidth may actually be expanded from its default setting, should you wish to enhance incoming signal fidelity when interference on the band is low.

  • Page 73: If Notch Filter Operation (Ssb/Cw/Rtty/Pkt/Am Modes)

    IF N SSB/CW/RTTY/PKT/AM M The IF Notch filter is a highly-effective system that allows you to slice out an interfering beat note or other carrier signal from inside the receiver passband. Main (VFO-A) Band IF Notch Operation MAIN(VFO-A) NTCH switch 1.

  • Page 74: Digital Noise Reduction (Dnr) Operation

    DNR O The Digital Noise Reduction (DNR) system is designed to reduce the level of random noise found on the HF and 50 MHz bands, and it is especially effective during SSB operation. By rotating the DNR knob, any of sixteen different noise- reduction algorithms can be selected;...

  • Page 75: Narrow (Nar) One-Touch If Filter Selection

    NARROW NAR O -T IF F Pressing the NAR switch provides one-touch, mode-specific selection of a narrow IF DSP filter setting that does not depend on the setting of the Width control. Pressing the NAR switch once more returns the bandwidth control to the Width/Shift system.

  • Page 76: Digital Notch Filter (Dnf) Operation

    DNF O The Digital Notch Filter (DNF) is an effective beat-cancelling filter that can null out a number of interfering beat notes inside the receiver passband. Because this is an Auto-Notch feature, there is no adjustment knob associated with this filter. Advice If a very strong interfering carrier is encountered, we recommend you first use the IF Notch filter, as it is the most effective notching tool in the receiver section.

  • Page 77: Effective Reception

    IF N NB O The FT 9000D includes an effective IF Noise Blanker, which can significantly reduce noise caused by automotive ignition systems. MAIN(VFO-A) Main (VFO-A) Band NB Operation NB switch 1. Press the Main (VFO-A) band’s NB switch (# MAIN(VFO-A) NB knob momentarily to reduce a short pulse noise such as from...

  • Page 78: Sloped Agc Operation

    AGC A The AGC system is designed to help compensate for fading and other propagation effects, with characteristics that can be of particular value on each operating mode. The basic objective of AGC is to maintain a constant audio output level once a certain minimum threshold of signal strength is achieved.

  • Page 79: Mute Feature Main (Vfo-A) Band

    AGC A SLOPED AGC Operation In traditional AGC systems, the audio output from the SLOPE transceiver becomes essentially fixed once the thresh- NORMAL old for AGC action is reached (usually several dozen dB above the no-signal noise floor). The FT 9000D, however, includes an innovative Sloped AGC system, that allows the audio volume to rise and fall slightly...

  • Page 80: Adjacent Channel Monitor (Acm) Cw Mode Only

    (VFO-A) B There may be occasions, during Dual Receive operation, when you want to silence the Main (VFO-A) receiver temporarily so as to concentrate on what’s being received on the Sub (VFO-B) receiver. The Mute feature makes this simple to accom- plish.
  • Page 81 CW M While operating on CW on the Main (VFO-A) band, the ACM feature provides a visual indicator of encroachment by another station (someone you may not be able to hear because of the tight DSP filter in your FT 9000D).

  • Page 82: Ssb/Am Mode Transmission (Let's Look At The Transmitter

    SSB/AM M MOX switch VOX switch 1. Selecting the Operating Mode The operating mode is selected using the MODE switches ) to the left of the Main Tuning Dial knob (# ), and the VFO (A or B) to which the selec- tion is applied is selected by pressing the A or B switch MODE switch...

  • Page 83: Phantom Voltage For Condenser Microphones

    SSB/AM M For powering a studio-quality condenser microphone connected to the front panel’s XLR (“Cannon”) connector, it is possible to enable a 48-volt DC line connected to that jack. Because the improper enabling of this voltage could cause damage to other microphone types, the simple process for enabling the voltage has been made somewhat complicated, so as to prevent the voltage from being enabled by accident.

  • Page 84: Using The Automatic Antenna Tuner

    The Automatic Antenna Tuner (hereinafter referred to as the “ATU”) built into each FT 9000D is crafted to ensure a 50- Ohm load for the final amplifier stage of the transmitter. We recommend that the ATU be used whenever you operate on the 9000D.

  • Page 85: About Atu Operation

    ATU O Figure 1 depicts a situation where normal tuning via the ATU has been successfully completed, and the tuning data has been stored in the ATU memory. The antenna system as seen by the transmitter is shown. In Figure 2, the operator has changed frequency, and the HI SWR LED has become illuminated. The operator presses and holds in the TUNE switch for two seconds to begin impedance matching using the ATU.

  • Page 86: Lithium Battery Replacement

    The memories for the ATU are backed up by a common Lithium backup battery (type CR2032 or equivalent). After two or more years of heavy use, you may notice that the tuner memories are not being maintained, and that you have to re-tune when returning to a frequency on which you had previously stored tuning data.
  • Page 87 Slide the front panel diagonally upward and outward. Figure 4 ATU Backup Battery CONTROL Unit Backup Switch Figure 5 Removal of the Lithium Backup Battery Inserting the Lithium Backup Battery After pushing in the direction of the arrow, Use your fingertip to push in the move your finger upward.

  • Page 88: Ssb/Am Mode Transmission

    SSB/AM M - SSB, AM M The Speech Processor is designed to increase “talk power” by increasing the average power output via a sophisticated compression technique. The result is improved intelligibility when conditions are difficult. 1. Adjust the MIC gain control (# ) for SSB use, as METER switch described on page 80.

  • Page 89: Adjusting The Ssb Transmitted Bandwidth

    SSB/AM M SSB T For transmission on SSB, a default bandwidth of 2.4 kHz is provided. This bandwidth provides reasonable fidelity along with good talk power, and is typical of the bandwidth used for decades during SSB transmission. However, the bandwidth may be varied by the operator, so as to provide different levels of fidelity or talk power, according to your preferences.

  • Page 90: Parametric Microphone Equalizer

    SSB/AM M The FT 9000D includes a unique Three-Band Parametric Microphone Equalizer, that provides precise, independent control over the low-, mid-, and treble-ranges in your voice wave-form. Quick Point H The Parametric Equalizer is a unique technique for adjusting the signal quality. Because the three ranges may be adjusted so precisely , it is possible to craft a response that provides a more natural and pleasant sound than you have ever experienced before.
  • Page 91 SSB/AM M +10dB Parametric Gain (dB)0 -10dB ～ ～ ～ 100 700Hz 700 1500Hz 1500 3200Hz 3-Stage Parametric Equalizer Adjustments: Front Panel Microphone Jack TX AUDIO 136 F-PRMTRC EQ1-FREQ “100” (Hz) ~ “700” (Hz) Center Frequency TX AUDIO 139 F-PRMTRC EQ2-FREQ “700”...

  • Page 92: Low- Distortion Class-A Operation

    SSB/AM M (L - D CLASS-A O CLASS-A O Class-A operation of the FT 9000D transmitter is provided, yielding ultra-low distortion products during SSB operation. Power output during Class-A operation is 75 Watts. To engage Class-A operation, press the CLASS-A switch ).
  • Page 93 SSB/AM M (L - D CLASS-A O CLASS-A O Quick Point H Class-A operation provides a significant improvement in transmitter distortion suppression. During Class-A, the 3rd- order IMD products are typically suppressed 50 dB, while the 5th- and higher-order IMD products (that can cause “splatter”...

  • Page 94: Voice Memory

    SSB/AM M You may utilize the Voice Memory capability of the FT 9000D by plugging in the supplied FH-2 Remote Control Keypad into the rear panel’s REMOTE jack. The Voice Memory system includes five memories capable of storing up to 20 seconds of voice audio each. The maximum that any memory can hold is 20 seconds.
  • Page 95 9000D O Page 93...

  • Page 96: Convenient Transmitter Accessories

    VOX: A TX/RX S SSB/AM/FM M Instead of using the microphone’s PTT switch or the front panel MOX switch to activate the transmitter, the VOX (Voice Operated TX/RX Control) system provides hands-free, automatic activation of the transmitter, based on voice input into the microphone.

  • Page 97: Split Operation Using The Tx Clarifier (Vfo-A Operation)

    TX C VFO-A O For split TX/RX operation in “casual” pile-ups, where the split is less than 10 kHz, the TX Clarifier (Offset Tuning) feature may be utilized. 1. Press the CLAR switch (# ). The Red LED im- TX switch CLAR switch bedded in the switch will light up.

  • Page 98: Split-Frequency Operation

    A powerful capability of the FT 9000D is its flexibility in Split Frequency operation, using the Main (VFO-A) and Sub (VFO-B) frequency registers. This makes the FT 9000D especially useful for high-level DX-pedition use, as the Split operation capability is very advanced and easy to use. MAIN(VFO-A) 1.

  • Page 99: Quick Split Operation

    Quick Split Operation The Quick Split feature allows you to set a one-touch offset of +5 kHz to be applied to your radio’s transmit frequency on the Sub VFO, compared to the Main (VFO-A) frequency. MAIN(VFO-A) 1. Start with regular transceiver operation on the Main TX switch “OFF”...

  • Page 100: Full Duplex Operation

    The FT 9000D includes a unique capability among HF Important Guidelines for Full Duplex Operation transceivers: the ability to operate in a full duplex envi- Remember that, at your station location, the capability ronment, where by you can transmit on the Main band exists for damaging RF voltage to be conducted from your (VFO-A) while simultaneously tuning around, on a differ- transmitting antenna into your receiving antenna during...
  • Page 101 9000D O Page 99...

  • Page 102: Cw Mode Operation

    CW M The powerful CW operating capabilities of the FT 9000D include operation using both an electronic keyer paddle and a “straight key” or emulation thereof, as is provided by a computer-based keying device. Before starting, connect your key line to the front and/or rear panel KEY jack, and be sure the KEYER switch on the left side of the front panel is turned off for now.

  • Page 103: Using The Built-In Electronic Keyer

    CW M Connect the cable from your keyer paddle to the front or rear panel KEY jack. 1. Press the CW mode switch CW key ) to engage CW operation. If you press the CW key once more, af- ter initially selecting CW, you will engage the “CW Reverse”...

  • Page 104: Setting The Keyer Weight (Dot/Space:dash ) Ratio

    CW M A number of interesting and useful features are available during Electronic Keyer operation. Setting the Keyer Weight (Dot/Space:Dash ) Ratio The Menu may be used to adjust the Weight for the built-in Electronic Keyer. The default weighting is 3:1 (a dash is three times longer than a dot or space).

  • Page 105: Cw Convenience Features

    DX station. From the DX side, if a dozen or more operators (also using Yaesu's SPOT system) all call precisely on the same frequency, PITCH knob...

  • Page 106: Using Cw Reverse

    CW C CW R If you experience a difficult interference situation, where CW switch an interfering station cannot readily be eliminated, you may wish to try receiving using the opposite sideband. This may throw the interfering station’s frequency in a direc- tion that may lend itself more readily to rejection.

  • Page 107: Cw Delay Time Setting

    CW C CW D During semi-break-in (not QSK) operation, the hang time of the transmitter, after you have finished sending, may be adjusted to a comfortable value consistent with your send- ing speed. This is the functional equivalent to the “VOX Delay”...

  • Page 108: Contest Memory Keyer

    CW C The rise and fall times of the CW envelope may be adjusted using the Menu. The default setting of 4 ms. is ideal for most operation, as it produces a nicely “rounded” shape to the CW character. However, the rise and fall times may be adjusted to 1/2/4/6 ms, as desired, using Menu item “MODE-CW 048 CW WAVE SHAPE.”...
  • Page 109 CW C Message Memory Programming (Using Your Paddle) Checking the CW Memory Contents 1. Press the CW mode switch (# ) to engage CW 1. Be sure that Break-in is still turned Off. operation. 2. Press the FH-2’s 1 ~ 5 key to check your work. 2.

  • Page 110: Text Memory

    CW C TEXT Memory The five channels of CW message memory (up to 50 characters total) may also be programmed using a text-entry tech- nique. This technique is somewhat slower than when you send the message directly from your keyer paddle, but accuracy of character spacing is ensured.

  • Page 111: Operation

    CW C Text Message Programming Checking the CW Memory Contents 1. Press the CW mode switch (# ) to engage CW 1. Be sure that Break-in is still turned Off. operation. 2. Press the FH-2’s 1 ~ 5 key to check your work. 2.

  • Page 112: Fm Mode Operation

    FM M 1. Press the FM mode key (# ) to select the FM op- erating mode. H Be sure that the FM mode is being selected on the proper VFO; check the status of the A and B switches above the mode selection keys before making your mode selection.

  • Page 113: Repeater Operation

    FM M The FT 9000D may be utilized on 29 MHz and 50 MHz repeaters. 1. Rotate the Main Tuning Dial knob (# ) to the output frequency (downlink) from the repeater. 2. If CTCSS Tone operation is desired/needed, press and hold in the FM Mode key (# ) for two seconds to engage the CTCSS mode.

  • Page 114: Convenient Memory Functions

    The FT 9000D contains ninety-nine regular memories, labeled 01 through 99, nine special programmed limit memory pairs, labeled P-1L/1U through P-9L/9U, and five QMB (Quick Memory Bank) memories, labeled C1 ~ C5. Each stores various settings, not only the main band's (VFO-A) frequency and mode (See below). By default, the 99 regular memories are contained in one group;...

  • Page 115: Qmb (Quick Memory Bank)

    UICK EMORY The Quick Memory Bank is comprised of five memories (labeled C1 ~ C5) independent from the regular and PMS memo- ries. These can quickly store operating parameters for later recall. QMB C 1. Tune to the desired frequency on the Main (VFO-A) band.

  • Page 116: Memory Groups

    1. Press the MNU key (# ) to enter the Menu mode. MNU key 2. Rotate the Main Tuning Dial knob (# ) to select Menu item “GENERAL 031 MEM GROUP.” Rotate the CLAR/VFO-B knob (# ) to set this Menu item to “ENABLE”...

  • Page 117: Memory Operation

    The memory system of the FT 9000D allows storage and recall of up to 99 memories, each storing frequency, mode, and a wide variety of status information detailed previously. Memories may be grouped into as many as six Memory Groups, and additionally you get nine pairs of band-limit (PMS) memories along with five QMB (Quick Memory Bank) memories.

  • Page 118: Checking A Memory Channel's Status

    Checking a Memory Channel’s Status Before programming a channel into memory, you can check the current contents of that channel without the danger of over-writing the data accidentally. switch 1. Press the MCH/GRP key (# ) momentarily. The imbedded LED will glow Red, indicating that you are now ready to view memory channel con- tents.

  • Page 119: Moving Memory Data To The Main (Vfo-A) Band

    VFO-A B You may transfer the contents of the currently-selected memory channel into the Main (VFO-A) band register, if you like. 1. Press the V/M switch (# ), as necessary, to go to switch the Memory mode. The memory channel number will appear in the multi-panel window.

  • Page 120: 5167.5 Khz (U.s. Version Only)

    : 5167.5 H (U.S. V Section 97.401(d) of the regulations governing amateur radio in the United States permit emergency amateur communica- tions on the spot frequency of 5167.5 kHz by stations in (or within 92.6 km of) the state of Alaska. This frequency is only to be used when the immediate safety of human life and/or property are threatened, and is never to be used for routine communications.

  • Page 121: Operation On The 60-Meter Band (U.s. Version)

    60-M (U.S. V The recently-released 60-meter band is covered, in the FT 9000D, by five special, fixed memory channels. These channels are set to USB, and they appear between the “last” PMS channel (“P9U”) and the first “regular” memory channel (Channel 1).

  • Page 122: Vfo And Memory Scanning

    You may scan wither the VFO or the memories of the FT 9000D, and the radio will halt the scan on any station with a signal strong enough to open the receiver’s squelch. VFO S 1. Press the A or B switch (# ) to select the VFO V/M switch to be scanned.

  • Page 123: Memory Scan

    To limit scanning (and manual tuning) within a particular frequency range, you can use the Programmable Memory Scan- ning (PMS) feature, which utilizes nine special-purpose memory pairs (“P-1L/P-1U” through “P-9L/P-9U”). The PMS feature is especially useful in helping you to observe any operating sub-band limits which apply to your Amateur license class.

  • Page 124: Packet Operation

    Packet operation is easily accomplished on the FT 9000D by connecting your TNC (Terminal Node Controller) to the transceiver, per the illustration. “Packet” operation also applies to SSB-based AFSK data modes, such as PSK31, etc. DATA DATA PACKET PACKET JACK ②...

  • Page 125: Rtty (Radio Teletype) Operation

    RTTY (R Most RTTY operation today is accomplished using a TNC or other computer-based system that utilizes AFSK tones. As such, the previous discussion on LSB-mode “Packet” operation will apply for Baudot operation, as well. For RTTY opera- tion using a Terminal Unit (TU) or the “FSK” output from a TNC, please see the discussion below. See also the illustration for details regarding connection to your TU.

  • Page 126: Miscellaneous Afsk-Based Data Modes

    AFSK- The FT 9000D may also me used for a host of other SSB-based Data modes. Please set up your system using the illustration as a guideline. PACKET ② ④ ⑤ ① ③ PACKET PTT DATA OUT LINE IN or MIC IN DATA IN LINE OUT or MIC OUT COM PROT...
  • Page 127 9000D O Page 125...

  • Page 128: Menu Mode

    The Menu system of the FT 9000D provides extensive customization capability, so you can set up your transceiver just the way you want to operate it. The Menu items are grouped by general utilization category, and are numbered from “AGC 1”...

  • Page 129: Menu Mode Setting Table

    Groupe No. MenuFunction Available Values Default Setting 001 MAIN-FAST-DELAY 20 ~ 4000 msec (20 msec Step) 300 msec 002 MAIN-FAST-HOLD 0 ~ 2000 msec (20 msec Step) 0 msec 003 MAIN-MID-DELAY 20 ~ 4000 msec (20 msec Step) 700 msec 004 MAIN-MID-HOLD 0 ~ 2000 msec (20 msec Step) 0 msec...
  • Page 130 Groupe No.MenuFunction Available Values Default Setting MODE-DAT 053 DATA IN SELECT DATA / PC DATA MODE-DAT 054 DATA GAIN 0 ~ 255 MODE-DAT 055 DATA OUT VFO-a / VFO-b VFO-a MODE-DAT 056 DATA VOX DELAY 30 ~ 3000 msec 300 msec MODE-DAT 057 DATA VOX GAIN 0 ~ 255 MODE-FM...
  • Page 131 Groupe No. MenuFunction Available Values Default Setting RX DSP 106 SUB-SSB-NARROW 200 / 400 / 600 / 850 / 1100 / 1350 / 1800 (Hz) 1500 / 1650 / 1800 / 1950 / 2100 / 2250 (Hz) SCOPE 107 MAIN FIX 1.8MHz 1800 ~ 1999 kHz 1800kHz SCOPE...
  • Page 132 Groupe No. MenuFunction Available Values Default Setting TX GNRL 155 TX PWR CONTROL ALL MODE / CARRIER ALL MODE TX GNRL 156 EXT AMP TX-GND ENABLE / DISABLE DISABLE TX GNRL 157 EXT AMP TUNING PWR 10 /50 / 100 / 200 (W) 100 (W) TX GNRL 158 FULL DUPLEX...

  • Page 133: Menu Mode Setting

    AGC G 007. SUB-FAST-DELAY 001. MAIN-FAST-DELAY Function: Sets the delay time for the AGC FAST mode Function: Sets the delay time for the AGC FAST mode of the sub band (VFO-B) receiver. of the main band (VFO-A) receiver. Available Values: 20 ~ 4000 msec (20 msec/step) Available Values: 20 ~ 4000 msec (20 msec/step) Default Setting: 300 msec Default Setting: 300 msec...
  • Page 134 DISPLAY G 013. TFT COLOR 017. ROTATOR START UP Function: Selects the TFT color. Function: Selects the starting point of your controller’s Available Values: COOL BLUE/CONTRAST BLUE/ indicator needle. FLASH WHITE/CONTRAST UMBER/UMBER Available Values: 0/90/180/270º Default Setting: COOL BLUE Default Setting: 0º 014.
  • Page 135 FH-2 SETUP G 021. BEACON TIME 024. CW MEMORY 2 Function: Sets the interval time between repeats of Function: Permits entry of the CW message for mes- the beacon message. sage register 2. Available Values: OFF/1 ~ 255 sec Available Values: TEXT/MESSAGE Default Setting: OFF Default Setting: MESSAGE TEXT:...
  • Page 136 GENERAL G 028. ANT SELECT 035. µTUNE DIAL STEP Function: Sets the method of antenna selection. Function: Select the µ-TUNE mode. Available Values: BAND/STACK Available Values: DIAL STEP-1/DIAL STEP-2/OFF Default Setting: BAND Default Setting: DIAL STEP-1 BAND: The antenna is selected in accordance with DIAL STEP-1: Activates the µ-TUNE system in the the operating band.
  • Page 137 MODE-AM G MODE-CW G 039. AM MIC GAIN 041. F-KEYER TYPE Function: Sets the microphone gain for the AM mode. Function: Selects the desired keyer operation mode Available Values: MCVR/0 ~ 255 (FIX) for the device connected to the front panel’s KEY jack. Default Setting: 160 Available Values: OFF/BUG/ELEKEY/ACS When this menu is set to “MCVR,”...
  • Page 138 MODE-CW G 045. CW AUTO MODE 049. CW WEIGHT Function: Enables/disables CW keying while oper- Function: Sets the Dot:Dash ratio for the built-in elec- ating on SSB. tronic keyer. Available Values: OFF/50MHz/ON Available Values: (1:) 2.5 ~ 4.5 Default Setting: OFF Default Setting: 3.0 OFF: Disables CW keying while operating on...
  • Page 139 MODE-DAT G MODE-FM G 053. DATA IN SELECT 058. FM MIC GAIN Function: Selects the data input to be used on the Function: Sets the microphone gain for the FM mode. PKT mode. Available Values: MCVR/0 ~ 255 (FIX) Available Values: DATA/PC Default Setting: 160 Default Setting: DATA When this menu is set to “MCVR,”...
  • Page 140 MODE-PKT G MODE-RTY G 062. PKT DISP 065. POLARITY-R Function: Sets the packet frequency display offset. Function: Selects normal or reverse Mark/Space po- Available Values: –3000 ~ +3000 Hz (10 Hz/step) larity for RTTY receive operation. Default Setting: 0 Hz Available Values: NOR/REV Default Setting: NOR 063.
  • Page 141 MODE-SSB G RX AUDIO G 069. SSB MIC SELECT 075. AGC-SLOPE Function: Selects the microphone to be used on the Function: Selects the gain curve of the AGC ampli- SSB mode. fier. Available Values: FRONT/REAR/DATA/PC Available Values: NORMAL/SLOPE Default Setting: FRONT Default Setting: NORMAL FRONT: Selects the microphone connected to the NORMAL: The AGC output level will follow a linear...
  • Page 142 RX DSP G 078. MAIN-CONTOUR-LEVEL 083. MAIN-CW-SHAPE Function: Adjusts the parametric equalizer gain of Function: Selects the passband characteristics of the main band (VFO-A) receiver Contour filter. the main band (VFO-A) DSP filter for the CW mode. Available Values: –20 ~ +10 dB Available Values: SOFT/SHARP Default Setting: –15 dB Default Setting: SHARP...
  • Page 143 RX DSP G 090. MAIN-RTTY-SLOPE 097. SUB-CW-NARROW Function: Selects the shape factor of the main band Function: Selects the passband of the sub band (VFO-A) DSP filter for the RTTY mode. (VFO-B) DSP filter for the CW “narrow” mode. Available Values: GENTLE/MEDIUM/STEEP Available Values: 25/50/100/200/300/400 Hz Default Setting: MEDIUM Default Setting: 300 Hz...
  • Page 144 RX DSP G SCOPE G 102. SUB-RTTY-SLOPE 107. MAIN FIX 1.8 MHz Function: Selects the shape factor of the sub band Function: Selects the scan start frequency of the FIX (VFO-B) DSP filter for the RTTY mode. mode Spectrum Scope while monitoring on the main Available Values: GENTLE/MEDIUM/STEEP band (VFO-A) 160 m amateur band.
  • Page 145 SCOPE G 115. MAIN FIX 24 MHz 123. SUB FIX 14 MHz Function: Selects the scan start frequency of the FIX Function: Selects the scan start frequency of the FIX mode Spectrum Scope while monitoring on the 12 m mode Spectrum Scope while monitoring on the 20 m amateur band.
  • Page 146 TUNING G TX AUDIO G 129. MAIN DIAL STEP 136. F-PRMTRC EQ1-FREQ Function: Setting of the Main Tuning Knob’s tuning Function: Selects the center frequency of the lower speed on the SSB, CW, and AM modes. range for the front panel’s parametric microphone Available Values: 1 or 10 Hz equalizer.
  • Page 147 TX AUDIO G 148. R-PRMTRC EQ2-FREQ 142. F-PRMTRC EQ3-FREQ Function: Selects the center frequency of the middle Function: Selects the center frequency of the high range for the rear panel’s parametric microphone range for the front panel’s parametric microphone equalizer. equalizer.
  • Page 148 TX GNRL G 154. TX MAX POWER 158. FULL DUPLEX Function: Selects a maximum output power limit. Function: Enables/Disables Full Duplex operation. Available Values: 200/100/50/10 W Available Values: SIMP/DUP Default Setting: 200 W Default Setting: SIMP When this menu is set to “DUP,” you may receive on 155.
  • Page 149 FT 9000D O Page 147...
  • Page 150 General Rx Frequency Range: 30 kHz - 60 MHz (Operating) 160 - 6 m (Amateur bands only) Tx Frequency Ranges: 160 - 6 m (Amateur bands only) Frequency Stability: ±0.03 ppm (after 5 min. @ –10 °C ~ +60 °C [+14 °F ~ +140 °F]) Operating Temperature Range: –10 °C ~ +60 °C [+14 °F ~ +140 °F] Emission Modes:...

  • Page 151: Specifications

    Receiver Circuit Type: Triple-conversion superheterodyne Intermediate Frequencies: VFO-A; 40.455 MHz/455 kHz/30 kHz (24 kHz for FM), VFO-B; 40.455 MHz/450 kHz/30 kHz (24 kHz for FM) Sensitivity (IPO “OFF”): SSB (2.4 kHz, 10 dB S+N/N) 0.2 µV (160 - 10 m Amateur bands) 0.125 µV (6 m Amateur band) 2 µV (0.1 - 50 MHz) AM (6 kHz, 10 dB S+N/N, 30 % modulation@400 Hz)
  • Page 152 FT 9000D O Page 150...
  • Page 153 FT 9000D O Page 151...
  • Page 154 FT 9000D O Page 152...
  • Page 155 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 156 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan VERTEX STANDARD US Headquarters 10900 Walker Street, Cypress, CA 90630, U.S.A. YAESU EUROPE B.V. P.O. Box 75525, 1118 ZN Schiphol, The Netherlands YAESU UK LTD. Unit 12, Sun Valley Business Park, Winnall Close Winchester, Hampshire, SO23 0LB, U.K.

This manual is also suitable for:

Ft dx 9000d

Table of Contents

Save PDF
