091. SUB-CW-APF/CONT
Function: Selects the Sub Band's (VFO-B) [ CONT ]
switch function.
Available Values: APF/CONTOUR/
APF&CONTOUR
Default Setting: APF&CONTOUR
APF: Press the Sub Band (VFO-B)
[ CONT ] switch to activate the
APF (Audio Peak Filter) which
provides a very narrow audio fil-
ter.
CONTOUR: Press the Sub Band (VFO-B)
[ CONT ] switch to activate the
Contour filter.
APF&CONTOUR: Press the Sub Band (VFO-B)
[ CONT ] switch to activate the
Contour filter. Or, press and hold
the Sub Band (VFO-B) [ CONT ]
switch for 2 seconds to activate
the APF (Audio Peak Filter)
which provides a very narrow au-
dio filter.
The APF (Audio Peak Filter) and Contour filter do
not work at the same time.
092. IF-NOTCH-WIDTH
Function: Selects the bandwidth of the DSP NOTCH
filter
Available Values: NARROW/WIDE
Default Setting: WIDE
093. MAIN-CW-SHAPE
Function: Selects the passband characteristics of
the Main band (VFO-A) DSP filter for the CW mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
094. MAIN-CW-SLOPE
Function: Selects the shape factor of the Main band
(VFO-A) DSP filter for the CW mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
095. MAIN-CW-NARROW
Function: Selects the passband of the Main band
(VFO-A) DSP filter for the CW "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
FT 9000D O
DX PERATION
RX DSP G
M
ANUAL
ROUP
096. MAIN-PSK-SHAPE
Function: Selects the passband characteristics of
the Main band (VFO-A) DSP filter for the PSK mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
097. MAIN-PSK-SLOPE
Function: Selects the shape factor of the Main band
(VFO-A) DSP filter for the PSK mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
098. MAIN-PSK-NARROW
Function: Selects the passband of the Main band
(VFO-A) DSP filter for the PSK "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
099. MAIN-RTTY-SHAPE
Function: Selects the passband characteristics of
the Main band (VFO-A) DSP filter for the RTTY mode.
Available Values: SOFT/SHARP
Default Setting: SHARP
SOFT: Primary importance attached to amplitude
of the filter factor.
SHARP: Primary importance attached to phase of
the filter factor.
100. MAIN-RTTY-SLOPE
Function: Selects the shape factor of the Main band
(VFO-A) DSP filter for the RTTY mode.
Available Values: GENTLE/MEDIUM/STEEP
Default Setting: MEDIUM
101. MAIN-RTTY-NARROW
Function: Selects the passband of the Main band
(VFO-A) DSP filter for the RTTY "narrow" mode.
Available Values: 25/50/100/200/300/400 Hz
Default Setting: 300 Hz
