164. P-PRMTRC EQ1-FREQ
Function: Selects the center frequency of the lower
range for the front panel's parametric microphone
equalizer when the speech processor is activated.
Available Values: OFF/100 ~ 700 Hz (100 Hz/step)
Default Setting: 200 (Hz)
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
100 ~ 700: You may adjust the equalizer gain and
Q-factor at this selected audio frequency
via menu items 165:
LEVEL LEVEL LEVEL LEVEL LEVEL and 166:
165. P-PRMTRC EQ1-LEVEL
Function: Adjusts the equalizer gain of the low range
of the front panel's parametric microphone equalizer
when the speech processor is activated.
Available Values: –20 ~ +10
Default Setting: 0
166. P-PRMTRC EQ1-BWTH
Function: Adjusts the Q-factor of the low range of
the front panel's parametric microphone equalizer
when the speech processor is activated.
Available Values: 1 ~ 10
Default Setting: 2
167. P-PRMTRC EQ2-FREQ
Function: Selects the center frequency of the middle
range for the front panel's parametric microphone
equalizer when the speech processor is activated.
Available Values: OFF/700 ~ 1500 Hz (100 Hz/step)
Default Setting: 800 (Hz)
OFF: The equalizer gain and Q-factor are set
to factory defaults (flat).
700 ~ 1500: You may adjust the equalizer gain and
Q-factor at this selected audio fre-
quency via menu items 168:
PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL PRMTRC EQ2-LEVEL
PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH
PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH PRMTRC EQ2-BWTH
168. P-PRMTRC EQ2-LEVEL
Function: Adjusts the equalizer gain of the middle
range of the front panel's parametric microphone
equalizer when the speech processor is activated.
Available Values: –20 ~ +10
Default Setting: 0
169. P-PRMTRC EQ2-BWTH
Function: Adjusts the Q-factor of the middle range
of the front panel's parametric microphone equalizer
when the speech processor is activated.
Available Values: 1 ~ 10
Default Setting: 1
FT 9000D O
DX PERATION
TX AUDIO G
P-PRMTRC EQ1- P-PRMTRC EQ1- P-PRMTRC EQ1-
P-PRMTRC EQ1- P-PRMTRC EQ1-
P-PRMTRC EQ1-BWTH P-PRMTRC EQ1-BWTH P-PRMTRC EQ1-BWTH P-PRMTRC EQ1-BWTH P-PRMTRC EQ1-BWTH .
P- P- P- P- P-
and 169: P- P- P- P- P-
.
M
ANUAL
ROUP
170. P-PRMTRC EQ3-FREQ
Function: Selects the center frequency of the high
range for the front panel's parametric microphone
equalizer when the speech processor is activated.
Available Values: OFF/1500 ~ 3200 Hz (100 Hz/
step)
Default Setting: 2100 (Hz)
OFF: The equalizer gain and Q-factor are
set to factory defaults (flat).
1500 ~ 3200: You may adjust the equalizer gain and
Q-factor in this selected audio fre-
quency via menu items 171:
PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL PRMTRC EQ3-LEVEL
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH PRMTRC EQ3-BWTH
171. P-PRMTRC EQ3-LEVEL
Function: Adjusts the equalizer gain of the high
range of the front panel's parametric microphone
equalizer when the speech processor is activated.
Available Values: –20 ~ +10
Default Setting: 0
172. P-PRMTRC EQ3-BWTH
Function: Adjusts the Q-factor of the high range of
the front panel's parametric microphone equalizer
when the speech processor is activated.
Available Values: 1 ~ 10
Default Setting: 1
M M
ENU ODE
P- P- P- P- P-
and 172:
P- P- P- P- P-
.
