Yaesu FTDX9000D - DATA MANAGEMENT Operation Manual page 152

M M
ENU ODE
049. F-KEYER TYPE
Function: Selects the desired keyer operation mode
for the device connected to the front panel's KEY
jack.
Available Values: OFF/BUG/ELEKEY/ACS
Default Setting: ELEKEY
OFF: Disables the front panel's keyer ("straight
key" mode for use with external keyer or
computer-driven keying interface).
BUG: Mechanical "bug" keyer emulation. One
paddle produces "dits" automatically, while
the other paddle manually produces
"dahs."
ELEKEY: Iambic keyer with ACS (Automatic Char-
acter Spacing) disabled.
ACS: Iambic keyer with ACS (Automatic Char-
acter Spacing) enabled.
050. F-CW KEYER
Function: Selects the keyer paddle's wiring configu-
ration of the KEY jack on the front panel.
Available Values: NOR/REV
Default Setting: NOR
NOR: Tip = Dot, Ring = Dash, Shaft = Ground
REV: Tip = Dash, Ring = Dot, Shaft = Ground
051. R-KEYER TYPE
Function: Select the desired keyer operation mode
for the device connected to the rear panel's KEY jack.
Available Values: OFF/BUG/ELEKEY/ACS
Default Setting: ELEKEY
OFF: Disables the front panel's keyer ("straight
key" mode for use with external keyer or
computer-driven keying interface).
BUG: Mechanical "bug" keyer emulation. One
paddle produces "dits" automatically, while
the other paddle manually produces
"dahs."
ELEKEY: Iambic keyer with ACS (Automatic Char-
acter Spacing) disabled.
ACS: Iambic keyer with ACS (Automatic Char-
acter Spacing) enabled.
052. R-CW KEYER
Function: Selects the keyer paddle's wiring configu-
ration of the KEY jack on the rear panel.
Available Values: NOR/REV
Default Setting: NOR
NOR: Tip = Dot, Ring = Dash, Shaft = Ground
REV: Tip = Dash, Ring = Dot, Shaft = Ground
Page 150
MODE-CW G
ROUP
053. CW AUTO MODE
Function: Enables/disables CW keying while oper-
ating on SSB.
Available Values: OFF/50MHz/ON
Default Setting: OFF
OFF:
50MHz: Enables CW keying only while operating
ON:
Note: This feature allows you to move someone from
SSB to CW without having to change modes on the
front panel.
054. CW BFO
Function: Sets the CW carrier oscillator injection side
for the CW mode.
Available Values: USB/LSB/AUTO
Default Setting: USB
USB:
LSB:
AUTO: Injects the CW carrier oscillator on the LSB
055. CW BK-IN
Function: Sets the CW "break-in" mode.
Available Values: SEMI/FULL
Default Setting: SEMI
SEMI: The transceiver will operate in the semi
FULL: The transceiver will operate in the full break-
056. CW WAVE SHAPE
Function: Selects the CW carrier wave-form shape
(rise/fall times).
Available Values: 1/2/4/6 msec
Default Setting: 4 msec
057. CW WEIGHT
Function: Sets the Dot:Dash ratio for the built-in elec-
tronic keyer.
Available Values: (1:) 2.5 ~ 4.5
Default Setting: 3.0
Disables CW keying while operating on
SSB.
SSB on 50 MHz (but not HF).
Enables CW keying while operating on
SSB (all TX bands).
Injects the CW carrier oscillator on the USB
side.
Injects the CW carrier oscillator on the LSB
side.
side while operating on the 7 MHz band and
below, and the USB side while operating on
the 10 MHz band and up.
break-in mode. The delay (receiver recov-
ery) time is set by the front panel's [ CW DE-
LAY ] knob.
in (QSK) mode.
