Groupe No.MenuFunction
GENERAL 045 MIC SCAN RESUME
GENERAL 046 AF/RF DIAL SWAP
MODE-AM 047 AM MIC GAIN
MODE-AM 048 AM MIC SELECT
MODE-CW 049 F-KEYER TYPE
MODE-CW 050 F-CW KEYER
MODE-CW 051 R-KEYER TYPE
MODE-CW 052 R-CW KEYER
MODE-CW 053 CW AUTO MODE
MODE-CW 054 CW BFO
MODE-CW 055 CW BK-IN
MODE-CW 056 CW WAVE SHAPE
MODE-CW 057 CW WEIGHT
MODE-CW 058 CW FREQ DISPLAY
MODE-CW 059 PC KEYING
MODE-CW 060 QSK
MODE-DAT 061 DATA IN SELECT
MODE-DAT 062 DATA GAIN
MODE-DAT 063 DATA OUT
MODE-DAT 064 DATA VOX DELAY
MODE-DAT 065 DATA VOX GAIN
MODE-FM 066 FM MIC GAIN
MODE-FM 067 FM MIC SELECT
MODE-FM 068 RPT SHIFT(28MHz)
MODE-FM 069 RPT SHIFT(50MHz)
MODE-PKT 070 PKT DISP
MODE-PKT 071 PKT GAIN
MODE-PKT 072 PKT SHIFT
MODE-RTY 073 POLARITY-R
MODE-RTY 074 POLARITY-T
MODE-RTY 075 RTTY SHIFT
MODE-RTY 076 RTTY TONE
MODE-SSB 077 SSB MIC SELECT
MODE SSB 078 SSB-TX-BPF
MODE-SSB 079 LSB RX-CARRIER
MODE-SSB 080 LSB TX-CARRIER
MODE-SSB 081 USB RX-CARRIER
MODE-SSB 082 USB TX-CARRIER
RX AUDIO 083 AGC-SLOPE
RX AUDIO 084 HEADPHONE MIX
RX AUDIO 085 SPEAKER OUT
RX DSP 086 MAIN-CONTOUR-LEVEL
RX DSP 087 MAIN-CONTOUR-WIDTH
RX DSP 088 MAIN-CW-APF/CONT
RX DSP 089 SUB-CONTOUR-LEVEL
RX DSP 090 SUB-CONTOUR-WIDTH
RX DSP 091 SUB-CW-APF/CONT
RX DSP 092 IF-NOTCH-WIDTH
RX DSP 093 MAIN-CW-SHAPE
RX DSP 094 MAIN-CW-SLOPE
RX DSP 095 MAIN-CW-NARROW
RX DSP 096 MAIN-PSK-SHAPE
RX DSP 097 MAIN-PSK-SLOPE
RX DSP 098 MAIN-PSK-NARROW
RX DSP 099 MAIN-RTTY-SHAPE
Page 142
Available Values
PAUSE / TIME
NORMAL / SWAP
MCVR / 0 ~ 255
FRONT / REAR / DATA / PC
OFF / BUG / ELEKEY / ACS
NOR / REV
OFF / BUG / ELEKEY / ACS
NOR / REV
OFF / 50M / ON
USB / LSB / AUTO
SEMI / FULL
1 / 2 / 4 / 6 msec
2.5 ~ 4.5
DIRECT FREQ / PITCH OFFSET
ENABLE / DISABLE
15 / 20 / 25/ 30 msec
DATA / PC
0 ~ 255
VFO-a / VFO-b
30 ~ 3000 msec
0 ~ 255
MCVR / 0 ~ 255
FRONT / REAR / DATA / PC
0 ~ 1000 kHz (10 kHz Step)
0 ~ 4000 kHz (10 kHz Step)
–3000 ~ 0 ~ 3000 Hz (10 Hz Step)
0 ~ 255
–3000 ~ 0 ~ 3000 Hz (10 Hz Step)
NOR / REV
NOR / REV
170 / 200 / 425 / 850 Hz
1275 / 2125 Hz
FRONT / REAR / DATA / PC
50-3000 / 100-2900 / 200-2800 /
300-2700 / 400-2600 (Hz) / 3000WB
–200 ~ 0 ~ 200 Hz (10Hz Step)
–200 ~ 0 ~ 200 Hz (10Hz Step)
–200 ~ 0 ~ 200 Hz (10Hz Step)
–200 ~ 0 ~ 200 Hz (10Hz Step)
NORMAL / SLOPE
SEPARATE / COMBINE-1 / COMBINE-2
SEPARATE / COMBINE
–40 ~ 0 ~ 20
1 ~ 11
APF / CONTOUR / APF&CONTOUR
–40 ~ 0 ~ 20
1 ~ 11
APF / CONTOUR / APF&CONTOUR
NARROW / WIDE
SOFT / SHARP
STEEP / MEDIUM / GENTLE
25 / 50 / 100 / 200 / 300 / 400 (Hz)
SOFT / SHARP
STEEP / MEDIUM / GENTLE
25 / 50 / 100/ 200 / 300 / 400 (Hz)
SOFT / SHARP
FT
Default Setting
TIME
NORMAL
160
FRONT
ELEKEY
NOR
ELEKEY
NOR
OFF
USB
SEMI
4 msec
3.0
PITCH OFFSET
DISABLE
15 msec
DATA
128
VFO-a
300 msec
128
128
FRONT
100 kHz
1000 kHz
0 Hz
128
1000 Hz
NOR
NOR
170 Hz
2125 Hz
FRONT
300-2700 (Hz)
0 Hz
0 Hz
0 Hz
0 Hz
NORMAL
SEPARATE
COMBINE
–15
10
APF&CONTOUR
–15
10
APF&CONTOUR
WIDE
SHARP
MEDIUM
300 (Hz)
SHARP
MEDIUM
300 (Hz)
SHARP
