Casio CLASSWIZ CG Software User's Manual page 8

Basic App Operations
Starting Up an Application
1. Press the h key to display the HOME screen.
2. Use the cursor keys to move the highlighting to the icon of the app you want to start up, and then press O.
Alternatively, you can press a number or letter key to select an app.
• If 1 is shown in the upper right corner of the icon you want to select, press 1. If A is shown, press X
App Screen Configuration
Status bar
The status bar at the top of the screen shows the current battery level, current settings, various statuses, and
help messages.
App window
This is the display area of the app. While the window displays a graph, you can hide the tabs to expand the
display area (see "Using Tabs" (page
Tab
Some applications of your calculator have multiple tabs. Each tab is assigned a role or function. The currently
active tab is white, while inactive tabs are black. Some apps do not have tabs.
Using Tabs
Some apps have tabs that are organized according to functions or properties.
• There are two types of apps with tabs, and the app type depends on the app organization.
One-way type: This type of app has a starting tab and an ending tab. App operations proceed sequentially
from the start (left-most) tab to the end (right-most) tab. Each press of > moves to the
next tab to the right.
Pressing < moves in reverse sequence (to the left) until the start (left-most) tab is reached.
8)).
Distribution App
8
Status bar
App window
Tab
A
.
