• This displays an animation table that shows the coordinates
of point F at each step of the animation in columns labeled
"X" and "Y".
5. Press b to close the animation table screen.
6. Press b twice to make the drawing screen active.
7. Press a, and then draw a line segment that connects point E and point C (line segment CE).
8. Select line segments CE and AB, and then press V.
• If the (angle) icon does not appear on the left edge of the
screen, highlight the up arrow to the left of the measurement
box and then press O. On the icon palette that appears,
select the icon.
9. Perform steps 3 through 4 above.
• An "Angle" column is added to the right of the "X" and "Y"
columns that were added in step 4, above.
10. To exit the animation table screen, press b.
*1 Instead of using the measurement box, you can also add an animation table by selecting T > [Animate]
> [Add Table]. However, this operation does not allow you to specify the type of measurement to be added
to the table. The first measurement that appears when the measurement box is displayed is added.
*2 When angle and supplementary angle are added to the animation table, the angle unit follows the setting
of S > [Angle] that is in effect at the time of addition. Changing the S > [Angle] setting does not affect
the values in the animation table that are already added.
Note
• You can add up to 26 columns to an animation table.
• Animation table contents are cleared whenever one of the operations below is performed.
- Using the Edit Animations screen to change an animation
- Adding or replacing an animation
- Specifying a new trace point
- Deleting a geometric element (line segment, point, etc.) used in an animation
- Launching an application other than the Geometry app
To display the animation table
To display the animation table you generated with the procedure under
179), select T > [Animate] > [Display Table].
(page
To save an animation table column to a list
1. Display the animation table.
2. Use l and r to highlight the column you want to save as list data.
3. Select T > [Store] > [List].
4. Use the dialog that appears to input a list number and then press O.
*1
*2
"To add columns to the animation table"
180
