Casio CLASSWIZ CG Software User's Manual page 114

Operations While a Graph is Displayed
To do this:
Specify the display range
Display a pointer on a graph and read
the coordinate values
Zoom in and out of the display
Draw dots, lines, characters, etc.
Grab a point on a window and drag it
around the display
Adjust the background image
Displaying a Numeric Table and Graph at the Same Time
When S > [Table with Graph] is turned on, the numeric table window is displayed on the right of the Table
tab and the graph window is displayed on the left.
• Nothing is drawn in the graph window immediately after you move to the Table tab from the Sequence tab.
Use the following operations to draw the graph.
- Select T > [Switch Active Window].
- From T, select the menu item for drawing a graph.
• Each time you select T > [Switch Active Window], the active window (the window that is affected by the
operations you perform) toggles between the numeric table window and the graph window. The numeric table
window is active when the cursor is displayed on the numeric table.
• While the numeric table window is active, you can perform the operations described under
Numeric Table is Displayed" (page
under "Operations While a Graph is Displayed" (page
Select this menu item:
T > [View Window]
T > [Trace]
T > [Zoom]
T > [Sketch]
T > [Pan]
T > [Fade I/O]
111). While the graph window is displayed, you can perform the operations
114), except for Pan and Fade I/O.
114
Details:
"Specifying the Display Range of
the Graph Window (View Window)"
(page 80)
"Using Trace (Trace)" (page 84)
"Changing the Graph Window Zoom
Setting (Zoom)" (page 81)
"Using Sketch (Sketch)" (page 85)
"Grabbing a Point on a Window and
Drag It Around the Display (Pan)"
(page 81)
"Adjusting the Graph Window
Background Image (Fade I/O)"
(page 81)
"Operations While a
