Casio CLASSWIZ CG Software User's Manual page 39

Border:
Broken Line Graph
Color:
Pie Chart
Display:
Pie Area:
- Area Color:
- Paint Style:
Pie Border:
Bar Graph
Stick Style:
D1 Area, D2 Area, D3 Area:
- Area Color:
- Paint Style:
D1 Border, D2 Border, D3 Border:
Normal Probability Plot
Mark Type:
Color:
Normal Density Curve
Color:
Drawing a 2-Variable Statistics Graph (Scatter Plot or Regression Graph)
You can perform the operations below based on 2-Variable statistical data you input into List Editor.
(1) Draw a Scatter Plot, xy Line Graph, or regression graph
(2) After drawing a graph, display summary statistics or regression model information
(3) Draw a regression graph over a graph described in (1) above
* Common practice in (1) is to draw a Scatter Plot and then draw a regression graph over it. You can also draw
a regression graph over a xy Line Graph or another regression graph.
Operation Flow
1. Use List Editor to input your data.
• For details, see "Inputting Data" (page
2. Use the procedure under
Statistics Graph].
• This causes the Draw Statistics Graph menu to appear on the Setup tab.
3. Select the type of graph you want to draw.
(1) Highlight [Graph1] and then press O.
• This causes the Setup tab display to change to the Graph1 setting menu.
(2) Press O again.
• This displays a menu for selecting the graph type.
• The menu includes both 1-Variable and 2-Variable graphs. Choose Scatter Plot, xy Line Graph, or
regression graph.
(3) Highlight the type of graph you want to draw from the menu and then press O.
Specifies the histogram border color. A border is not drawn if [Clear] is selected.
Specifies the graph draw color.
Specifies the data display form.
[%]: Percentages
[Data]: Values
Specifies the fill color of the pie chart.
Same as Histogram.
Same as Box Plot.
Specifies the border color of the pie chart. A border is not drawn if [Clear] is selected.
Specifies the orientation of the bars.
[Length]: Vertical
[Horizontal]: Horizontal
Specifies the fill color of each bar for Data1, Data2, and Data3
Same as Histogram.
Same as Box Plot.
Specifies the border color of each bar for Data1, Data2, and Data3. Borders are not
drawn if [Clear] is selected.
Specifies the mark to use for the plot.
Specifies the graph draw color.
Specifies the graph draw color.
29).
"Selecting What You Want to Do with the Statistics App" (page 29)
*
39
to select [Draw
