Casio CLASSWIZ CG Software User's Manual page 171

View Window settings are reconfigured in order to ensure that specifying a measurement of an object
does not make it too big to fit on the screen or too small to see.
Note that all other objects currently on the screen also are resized by the same amount as the object
whose measurement you are specifying.
• Once you specify one measurement of an object, it is not resized further if you specify another of its
measurements.
Locking or Unlocking a Measurement of an Object
As described in "Specifying and Locking a Measurement of an Object" (page
automatically locked as soon as it is specified numerically. This section describes how to lock or unlock a
measurement without specifying a numeric value.
Note
• Only some measurements of an object can be locked. For information about which measurements can
be locked, see the "Measurement Icon Table" (page
To lock a particular measurement
Example 1: To lock the length or slope of a line segment
1. Draw a line segment and select it.
2. Press V to display the measurement box.
3. Press l to highlight the up arrow button to the left of the measurement box and then press O.
4. On the icon palette that appears, highlight the icon (
then press O.
5. Use r to highlight the
• The icon changes to
Length locked
* You can also perform the steps below in place of step 5.
(1) Highlight the up arrow button to the right of the
(2) On the menu that appears, select [Lock] and then press O.
Example 2: To lock two sides of a triangle to equal lengths
1. Draw a triangle, and then select its side AC and side BC.
2. Press V to display the measurement box.
3. Press l to highlight the up arrow button to the left of the measurement box and then press O.
4. On the icon palette that appears, highlight the
• This causes "No" to appear in the measurement box.
5. Use r to highlight the
*
icon and press O.
, indicating that the measurement is locked.
icon and press O.
168).
or ) of the measurement you want to lock and
icon and press O.
icon and then press O.
171
170), a measurement is
Slope locked
