Casio CLASSWIZ CG Software User's Manual page 161

To specify the color and thickness of a line
1. Select the line whose color and thickness you want to specify.
• If you want to specify the color and thickness for all sides
of a polygon simultaneously, press P to select the entire
polygon (see "Select an entire polygon" under
Deselecting Objects" (page
2. Select T > [Color Select] > [Line Style]. On the menu that appears, select the desired line style.
3. Select T > [Color Select] > [Line Color]. On the menu that appears, select the desired color.
4. To apply the settings you configure, press b.
• Press a to deselect all objects.
To specify fill color and intensity of a closed figure (polygon, circle, etc.)
1. Select the closed figure whose fill color and intensity you want to specify.
• To fill a polygon or semicircle, press P to select the entire figure. To fill a circle, select its circumference.
2. Select T > [Color Select] > [Area Color]. On the menu that appears, select the desired color.
3. Select T > [Color Select] > [Paint Style]. On the menu that appears, select "Normal" or "Lighter".
4. To apply the settings you configure, press b.
Note
• You can also select three arbitrary points (the vertices of a polygon,
the center of a circle, the edge of a line segment, etc.) and specify
the fill color and intensity of the area enclosed within the three points.
Select the three points in step 1 above.
Note that this operation is possible only when three points are
selected. This operation is not performed if four or more points are
selected.
Using the File Menu
The table below shows the file operations that you can perform with the Geometry app.
To do this:
Clear the current drawing and create a new file
Clear the current drawing and open the Geometry app file stored
in Main Memory
Clear the current drawing and open an image file (.g4p or .g3p)
or Geometry app file (.g4p)
in Storage Memory
Name and save the current drawing
Delete the Geometry app file stored in Main Memory
"Selecting and
158)).
*2
with the background image stored
Select this menu item:
T > [File] > [New]
T > [File] > [Open] > [Main Memory]
*1 T > [File] > [Open] > [Storage Memory]
T > [File] > [Save As]
T > [File] > [Delete] > [Main Memory]
161
