Casio CLASSWIZ CG Software User's Manual page 153

Geometry App
Select h > Geometry to start up the Geometry app. This app allows you to draw and analyze geometric
objects. For example, you can draw a circle and then draw a line that is tangent to a particular point on the
circle.
The Geometry app also includes an animation feature that lets you watch how a figure changes in accordance
with conditions you define.
Note
• Changes to the Angle, Grid, or Axes settings of the Settings menu in the Geometry app, affect only the
Geometry app. They do not affect other apps. Conversely, changes made to these settings in other
apps do not affect the Geometry app.
• The initial default setting of the Geometry app's Angle setting is Degree.
• The examples in this chapter assume Geometry app initial default settings are in use (which are
configured when a new file is created as described under
otherwise noted.
Drawing and Editing Objects
This section explains how to perform the following operations.
• Plot points, draw line segments, polygons, etc. (Draw menu, Draw Special menu)
• Insert text into screen images
• Undo an operation
• Select and deselect objects, move an object, delete an object and other editing operations
Using the Pointer
You can use the following operations to move the on-screen pointer ( ) around the display when drawing
objects, editing objects, etc.
To move the pointer
Use the cursor keys (d/u/l/r) to move the pointer around the display. Holding down a cursor key moves
the pointer at high speed.
To make the pointer jump to a particular location
Pressing a number key (1 to 9) causes the pointer to jump to the corresponding location of the screen as
shown below.
"Using the File Menu" (page
153
161)), unless
