• If the graph you selected in step 3-(2) is a Histogram or Broken Line Graph, a dialog box appears where
you can specify Start ( x -coordinate of the graph drawing start point) and Width (graph drawing width).
Input each of the values, highlight
• For information about the operations you can perform on the Graph tab, see
(page 41).
7. To view summary statistics, press >. (This operation cannot be used for a Pie Chart.)
• This causes the summary statistics to appear on the Results tab. You can use d and u to scroll the
display contents.
• For the meanings of the displayed summary statistics values, see
Setting Items for Each 1-Variable Statistics Graph Type
Box Plot
Outliers:
Box:
Whisker:
OutlierColor:
Box Inside:
- Area Color:
- Paint Style:
Note
• Changing the S > [Q1Q3 Type] setting may alter the position of Q1 and Q3 even if Box Plot is
drawn based on the same data.
Histogram
Area:
- Area Color:
- Paint Style:
, and then press O.
Shows or hides outlier dots in a Box Plot.
[On]: Show
[Off]: Hide
minX
Q1
Med
Specifies the color of the border of the box area from Q1 to Q3, and the Med line.
Specifies the color of the lines extending from the ends of the box to minX and maxX.
Specifies the color of the outlier dots.
Specifies the fill color of the box area from Q1 to Q3.
Specifies the fill color.
Selecting [Auto] fills the area inside of the box from Q1 to Med with blue
and fills the inside of the box from Med to Q3 with yellow.
Specifies the density of the fill color.
[Normal]: Normal density fill
[Lighter]: Lighter density fill
Specifies the fill color of the histogram.
Specifies the fill color.
Selecting [Auto] automatically colors each data item, cycling through six
colors in the following sequence: blue, red, green, magenta, cyan, yellow.
Same as Box Plot.
"Summary Statistics" (page
maxX
Outlier dot
Q3
38
"Graph Window Operations"
33).
