Casio CLASSWIZ CG Software User's Manual page 167

Note
• If you select only part of an object before performing step 3 of the above procedure, only the selected
part is translated.
Other Transformation Operations
Before starting any of the operations shown in the table below, draw the figure you want to transform and then
select the entire figure. If you select only part of an object, only the selected part is transformed.
To do this: Select this menu item:
Translate an object T > [Transformations]
by specified values
> [Translation (Enter
Vector)]
Rotate an object T > [Transformations] >
[Rotation]
Dilate an object T > [Transformations] >
[Dilation]
Rotate an object
T > [Transformations] >
180 degrees on a
[Point Reflection]
specified point
Note
• The following figure illustrates the meanings of the terms used in the dilation procedure above.
Scale: -1
And then perform this operation:
1. On the Translation screen that appears, input the values
for the translation distance along the x -axis and the
translation distance along the y -axis.
2. Select
1. While the message "Select Center of Rotation" is
displayed, move the pointer to the location you want
to specify as the center of rotation, and then press O.
2. On the dialog box that appears, input the angle of
rotation (counterclockwise) in degrees and then press
O.
1. While the message "Select Center of Dilation" is
displayed, move the pointer to the location you want
to specify as the center of dilation, and then press O.
2. On the dialog box that appears, input a scale value in
the range of 0.1 ≤ | x | ≤ 10 and then press O.
• See the figure in the Note below for details about
the meanings of the terms used during the dilation
operation.
While the message "Select Center Point" is displayed, move
the pointer to the location you want to specify as the center
of rotation, and then press O.
• This draws the figure rotated 180 degrees on the selected
point. In addition, a point is plotted at the center point.
Original Object
Center of Dilation
Scale: 0.5
167
and then press O.
Scale: 2
