Table 17 describes the LEDs on the system board and the suggested actions for correcting any detected
problems.
Table 17. IBM Flex System p24L Compute Node
v Follow the suggested actions in the order in which they are listed in the Action column until the problem is
solved.
v See Chapter 7, "Parts listing for IBM Flex System p24L Compute Node," on page 79 to determine which
components are CRUs and which components are FRUs.
v If an action step is preceded by Trained service technician only, that step must be performed only by a trained
service technician.
Light path
diagnostics LED is
lit Description
None An error occurred and cannot be isolated, or
the service processor failed.
Battery error A battery error occurred.
P1-E1
DIMM x error A memory error occurred.
P1-C1 DIMM 1
P1-C2 DIMM 2
P1-C3 DIMM 3
P1-C4 DIMM 4
P1-C5 DIMM 5
P1-C6 DIMM 6
P1-C7 DIMM 7
P1-C8 DIMM 8
P1-C9 DIMM 9
P1-C10 DIMM 10
P1-C11 DIMM 11
P1-C12 DIMM 12
P1-C13 DIMM 13
P1-C14 DIMM 14
P1-C15 DIMM 15
P1-C16 DIMM 16
Drive 1 error An error occurred on drive 1.
P1-D1
P1-C17-D1
Drive 2 error An error occurred on drive 2.
P1-D2
P1-C17-D2
Network adapter A network adapter error occurred.
error
P1-C18
P1-C19
Action
An error occurred that is not represented by a
light path diagnostics LED. Check the event
log for information about the error.
Replace the battery, as described in "Removing
the battery" on page 51 and "Installing the
battery" on page 52.
1. Verify that the DIMM indicated by the lit
LED is a supported memory module, as
described on the ServerProven website.
2. Replace the DIMM indicated by the lit
LED, as described in "Removing a DIMM"
on page 44 and "Installing a DIMM" on
page 46.
Note: Multiple DIMM LEDs do not
necessarily indicate multiple DIMM failures. If
more than one DIMM LED is lit, replace one
DIMM at a time until the error goes away.
Replace the disk drive or solid-state drive. See
"Removing a SAS hard disk drive" on page 36
or "Removing a SATA solid-state drive" on
page 42.
Replace the solid-state drive. See "Removing a
SATA solid-state drive" on page 42.
1. Make sure that the network adapter is
supported.
2. Replace the network adapter, as described
in "Removing a network adapter" on page
49 and "Installing a network adapter" on
page 50.
If you are still having problems, see the
ServerProven website.
