Specifications

3.1

Feature List

Table 2 Feature Summary
Form Factor
Supported Modules
Power
Back Panel I/O
Connectors
Onboard I/O
Connectors
Other Features
Note
The module must also support features for them to function. Refer to the module's user's guide for information about supported features.
Copyright © 2025 congatec GmbH
®
Based on COM Express standard pinout Type 6, rev. 3.1
®
COM Express Type 6 compact and basic form factor
1 x standard 24-pin and 4-pin ATX connectors
1 x DC power input (4 mm banana connectors)
1 x CR2032 CMOS/RTC battery
1 x DP++ port
2 x USB4 ports
4 x USB 3.1 ports
1 x USB client port
1 x PEG x16 slot
1 x PCIe x4 slot
2 x PCIe x1 slot
1 x VGA port
1 x M.2 Key B socket
1x M.2 Key E socket
1 x micro-SIM card socket
1 x SD card socket (full-size)
1 x LVDS connector
1 x eDP connector
1 x Panel and Backlight Power header
1 x EPI EEPROM Socket
1 x Beeper
4 x Buttons (power, reset, sleep, lid)
8 x Ground test points
Four 14-segment displays for POST code information
HD audio codec (92HD91)
Super I/O (Nuvoton NCT6122D)
1 x 2.5 Gigabit Ethernet RJ45 port
1 x Microphone jack
1 x Line-OUT jack
1 x Optical S/PDIF-Out port
4 x SATA connectors (one connector supports SATADOM)
1 x SATA power connector
1 x Disk drive 4-pin connector
1 x HDA/SoundWire adapter/debug header
1 x I C EEPROM socket
2
1 x BIOS SPI flash socket SOIC16
1 x LPC/eSPI header
4 x COM port headers
1 x CAN connector
2 x Fan headers
1 x SBM header
1x Dual USB2.0 header
1x GP_SPI header
1 x Feature connector
