4.2

COM Express C - D Connector

Table 4 Module Type 6 Connector Pinout—Rows C and D
Pin Row C
C1 GND (FIXED)
C2 GND
C3 USB_SSRX0-
C4 USB_SSRX0+
C5 GND
C6 USB_SSRX1-
C7 USB_SSRX1+
C8 GND
C9 USB_SSRX2-
C10 USB_SSRX2+
C11 GND (FIXED)
C12 USB_SSRX3-
C13 USB_SSRX3+
C14 GND
C15 USB4_1_LSTX
C16 USB4_1_LSRX
C17 USB4_RT_ENA
C18 GND
C19 PCIE_RX6+
C20 PCIE_RX6-
C21 GND (FIXED)
C22 PCIE_RX7+
C23 PCIE_RX7-
C24 DDI1_HPD
C25 SML0_CLK
C26 SML0_DAT
C27 SML1_CLK
C28 SML1_DAT
Copyright © 2025 congatec GmbH
Pin Row D
D1 GND (FIXED)
D2 GND
D3 USB_SSTX0-
D4 USB_SSTX0+
D5 GND
D6 USB_SSTX1-
D7 USB_SSTX1+
D8 GND
D9 USB_SSTX2-
D10 USB_SSTX2+
D11 GND (FIXED)
D12 USB_SSTX3-
D13 USB_SSTX3+
D14 GND
D15 DDI1_CTRLCLK_AUX+/USB4_1_AUX+
D16 DDI1_CTRLDATA_AUX- /USB4_1_AUX-
D17 USB4_PD_I2C_ALERT#
D18 PMCALERT#
D19 PCIE_TX6+
D20 PCIE_TX6-
D21 GND (FIXED)
D22 PCIE_TX7+
D23 PCIE_TX7-
D24 GND
D25 GND
D26 DDI1_PAIR0+ /
USB4_1_SSTX0+
D27 DDI1_PAIR0- /
USB4_1_SSTX0-
D28 GND
Pin Row C
C56 PEG_RX1-
C57 TYPE1#
C58 PEG_RX2+
C59 PEG_RX2-
C60 GND (FIXED)
C61 PEG_RX3+
C62 PEG_RX3-
C63 GND
C64 GND
C65 PEG_RX4+
C66 PEG_RX4-
C67 RAPID_SHUTDOWN
C68 PEG_RX5+
C69 PEG_RX5-
C70 GND (FIXED)
C71 PEG_RX6+
C72 PEG_RX6-
C73 GND
C74 PEG_RX7+
C75 PEG_RX7-
C76 GND
C77 GND
C78 PEG_RX8+
C79 PEG_RX8-
C80 GND (FIXED)
C81 PEG_RX9+
C82 PEG_RX9-
C83 GND
TEVA31_m001
Pin Row D
D56 PEG_TX1-
D57 TYPE2#
D58 PEG_TX2+
D59 PEG_TX2-
D60 GND (FIXED)
D61 PEG_TX3+
D62 PEG_TX3-
D63 GND
D64 GND
D65 PEG_TX4+
D66 PEG_TX4-
D67 GND
D68 PEG_TX5+
D69 PEG_TX5-
D70 GND (FIXED)
D71 PEG_TX6+
D72 PEG_TX6-
D73 GND
D74 PEG_TX7+
D75 PEG_TX7-
D76 GND
D77 GND
D78 PEG_TX8+
D79 PEG_TX8-
D80 GND (FIXED)
D81 PEG_TX9+
D82 PEG_TX9-
D83 GND
