Specifications

2.1

Feature List

Table 1 Feature Summary
Form Factor
Processor
Memory
congatec Board
Controller
Chipset
Audio
Ethernet
Graphics Options
Peripheral
Interfaces
BIOS
Power Management
Security
Copyright © 2013 congatec AG
Based on COM Express™ standard pinout Type 6 Rev. 2.1 (Compact size 95 x 95 mm).
Intel Core™ i7-4650U 1.7 GHz Dual Core™ with 4-MByte Intel
®
Intel Core™ i5-4300U 1.9 GHz Dual Core™ with 3-MByte Intel
®
Intel Core™ i3-4010U 1.7 GHz Dual Core™ with 3-MByte Intel
®
Intel Celeron 2980U 1.6 GHz Dual Core™ with 2-MByte Intel
® ®
2 sockets: SO-DIMM DDR3L (Low voltage @ 1.35V) up to 1600MT/s, with 16GB maximum capacity. Sockets located top and bottom side of module.
Multi-stage watchdog, non-volatile user data storage, manufacturing and board information, board statistics, BIOS setup data backup, I2C bus, Power
loss control.
Intel 8 Series PCH-LP integrated in the Multi-Chip Package (MCP).
®
High Definition Audio (HDA)/digital audio interface with support for multiple codecs
Gigabit Ethernet support via the onboard Intel
Next Generation Intel HD Graphics (4400/5000) with support for Intel
®
Video Acceleration (full AVC/VC1/MPEG2 hardware decode), OpenGL 4.0 and DirectX11.1. Up to 3 independent displays supported (Must be two DDI's
(DP, HDMI/DVI) plus one eDP/LVDS)
• LVDS (Integrated flat panel interface with 25-112MHz single/dual-channel
LVDS Transmitter). Supports:
• Single-channel LVDS interface: 1 x 18 bpp or 1 x 24 bpp.
• Dual channel LVDS interface: 2 x 18 bpp or 2 x 24 bpp panel.
• VESA LVDS color mappings
• Automatic Panel Detection via Embedded Panel Interface based on
VESA EDID™ 1.3.
• Resolution up to 1920x1200 in dual LVDS bus mode.
• Optional eDP interface
(NOTE: Either eDP or LVDS signals supported. Both not supported).
• 4x Serial ATA 6Gb/s with RAID support 0/1/5/10 (Celeron variant
®
supports only 2x SATA 6Gb/s)
• 4 PCI Express Lanes. Support for full 5 Gb/s bandwidth in each direction
®
per x1 links. (can be configured via special/customized BIOS firmware to
support four x1 and one x4 links.
• 8x USB 2.0 (EHCI)
• 2x USB 3.0 (XHCI)
AMI Aptio UEFI 2.x firmware, 8/16 MByte serial SPI with congatec Embedded BIOS features.
®
• ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3) and Intel AMT 9.5.
• Configurable TDP
• Ultra low standby power consumption, Deep Sx.
Optional discrete Trusted Platform Module "TPM", new AES Instructions for faster and better encryption.
Smart Cache
®
Smart Cache
®
Smart Cache
®
Smart Cache
®
l218LM GbE Phy. Also offers AMT 9.5 support.
®
Clear Video Technology (HD encode/transcode, Blu-ray playback), DirectX
®
• DisplayPort 1.1 (DP): 2x DisplayPorts ports on digital ports B, C.
Multiplexed with HDMI/DVI ports. Hot-Plug detect support.
• HDMI 1.4: 2x HDMI ports on digital ports B, C. Multiplexed with
DisplayPort (DP)/DVI. Hot-plug detect support.
• DVI: 2x DVI ports on digital ports B, C. Multiplexed with HDMI/DP
ports. Hot-Plug detect support.
• Optional VGA interface
(NOTE: This option is offered on digital port C and supported only on rev.
C.x. and later. The display combination for revisions with VGA support is
1x DDI, 1x VGA and 1x eDP).
• 2x Serial Interface (UART0/1)
• LPC Bus
• I²C Bus, Fast Mode, multi-master
• SM Bus
• SPI
• GPIOs
