Pin Row A Pin
A27 BATLOW#
A28 (S)_ATA_ACT#
A29 HDA_SYNC
A30 HDA_RST#
A31 GND (FIXED)
A32 HDA_BITCLK
A33 HDA_SDOUT
A34 BIOS_DIS0#
A35 THRMTRIP#
A36 USB6-
A37 USB6+
A38 USB_6_7_OC#
A39 USB4-
A40 USB4+
A41 GND (FIXED)
A42 USB2-
A43 USB2+
A44 USB_2_3_OC#
A45 USB0-
A46 USB0+
A47 VCC_RTC
A48 RSMRST_OUT#
A49 GBE0_SDP
A50 LPC_SERIRQ (ESPI_CS1# )
1
A51 GND (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5-
A54 GPI0
A55 PCIE_TX4+
Note
1. Not supported
Copyright © 2025 congatec GmbH
Row B
B27 WDT
B28 HDA_SDIN2/SNDW0_CLK
B29 HDA_SDIN1/SNDW0_DAT
B30 HDA_SDIN0
B31 GND (FIXED)
B32 SPKR
B33 I2C_CK
B34 I2C_DAT
B35 THRM#
B36 USB7-
B37 USB7+
B38 USB_4_5_OC#
B39 USB5-
B40 USB5+
B41 GND (FIXED)
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47 ESPI_EN#
B48 USB0_HOST_PRSNT
B49 SYS_RESET#
B50 CB_RESET#
B51 GND (FIXED)
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
Pin Row A
A82 eDP_TX3-/LVDS_A_CK-
A83 eDP_AUX+/LVDS_I2C_CK
A84 eDP_AUX-/LVDS_I2C_DAT
A85 GPI3
A86 GP_SPI_MOSI
A87 eDP_HPD
A88 PCIE_CLK_REF+
A89 PCIE_CLK_REF-
A90 GND (FIXED)
A91 SPI_POWER
A92 SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 TPM_PP
A97 TYPE10#
A98 SER0_TX
A99 SER0_RX
A100 GND (FIXED)
A101 SER1_TX
A102 S ER1_RX
A103 LID#
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND (FIXED)
TEVA31_m001
Pin Row B
B82 LVDS_B_CK-
B83 eDP/LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED
B90 GND (FIXED)
B91 VGA_GRN
B92 VGA_BLU
B93 VGA_HSYNC
B94 VGA_VSYNC
B95 VGA_I2C_CK
B96 VGA_I2C_DAT
B97 SPI_CS#
B98 GP_SPI_MISO
B99 GP_SPI_CK
B100 GND (FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
