Audio Interfaces - Congatec conga-TEVAL3/COMe 3.1 User Manual

Com express type 6 revision 3.1 evaluation carrier board

4.10

Audio Interfaces

The conga-TEVAL3/COMe 3.1 features:

1. an HD audio codec TSI 92HD91B which provides:

– Line-Out signals on connector X47 (upper jack)

– MIC-In signals on connector X47 (lower jack)

– Optical S/PDIF output signal on connector X48

2. an HDA/SoundWire adapter/debug header on connector X49

Note

1. To disable the onboard codec, set DIP SW 9.2 to ON. See section 4.10.4 "HDA/SoundWire Adapter/Debug Header" for DIP SW 9.2

configuration .

2. The Windows driver for the codec can be found on the congatec website at www.congatec.com in the 'Products' section under 'Accessories'.

TEVA31_m001

44/62
