4.3
Power Supply Connector
The conga-TEVAL3/COMe 3.1 provides the following connectors for power supply:
• standard 24-pin ATX power connector (X63)
• standard 4-pin ATX12V power connector (X67)
• 12 V DC banana jack (X41 and X42)
Note
1. In ATX mode, the +3.3 V, +5 V and +12 V are derived from the ATX power supply. If you supply 12 V DC power via the DC banana jack,
the onboard DC/DC regulators will generate the 3.3 V, 5 V and 12 V.
2. In ATX mode, a 4-pin ATX connector is used to supply COM Express
®
module and a 24-pin ATX connector to the supply carrier board.
3. Do not supply power to both the DC banana jack and the ATX connectors at the same time.
Copyright © 2025 congatec GmbH
TEVA31_m001
21/62
