2

Specifications

2.1

Feature List

Table 4 Feature Summary
Form Factor
Processor
Memory
congatec Board
Controller
Chipset
Audio
Ethernet
Graphics
Options
Peripheral
Interfaces
BIOS
Storage
Power
Management
Security
Copyright © 2017 congatec GmbH
Based on COM Express™ standard pinout Type 6 Rev. 2.1 (Compact size 95 x 95 mm)
Intel Atom™, Pentium and Celeron SoC
® ®
Two memory sockets (located on the top and bottom side). Supports
SO-DIMM non-ECC DDR3L modules
-
Data rates up to 1866 MT/s
-
Maximum 8 GB capacity
-
Multi-stage watchdog, non-volatile user data storage, manufacturing and board information, board statistics, hardware monitoring, fan control, I2C bus,
Power loss control
Integrated in SoC
High Definition Audio interface with support for multiple codecs
Gigabit Ethernet (Intel i210-IT / i211-AT controller)
®
Next Generation Intel HD (500/505). Supports:
®
API (DirectX 12, OpenGL 4.3, OpenCL 2.0, OpenGL ES 3.0)
-
Intel ® QuickSync & Clear Video Technology HD (hardware accelerated video decode/encode/processing/transcode)
-
Up to 3 independent displays (must be two DP++ (DP, HDMI/DVI) and one eDP/LVDS)
-
2x DP++
1x LVDS
1x Optional eDP 1.3
1x Optional VGA
Resolutions up to 4K
8x USB 2.0 (up to 4x USB 3.0)
2x SATA ® (6 Gbps)
2x UART
3x PCI Express Gen. 3 lanes
®
GPIOs
LPC
I C (fast mode, multi-master)
2
AMI Aptio ® V UEFI 2.x firmware, 8 or 16 MB serial SPI with congatec Embedded BIOS features
Optional eMMC 5.0 onboard flash
ACPI 4.0 compliant with battery support. Also supports Suspend to RAM (S3) and Intel AMT 10
Configurable TDP
Ultra low standby power consumption, Deep Sx
Firmware TPM 2.0 (Intel ® PTT)
Discrete LPC TPM 2.0 (Infineon SLB9665) or LPC TPM 1.2 (Infineon SLB9660) support via assembly option
NOTE:
Variants that feature optional eDP interface do not support LVDS
*1
Variants that feature optional VGA interface support only 1x DDI
*2
The conga-TCA5 does not natively support TMDS. A DP++ to TMDS
*3
converter (e.g. PTN3360D) needs to be implemented
SMB
SPI
NOTE:
Five PCIe lanes for variants that feature PCIe switch
*1
Four PCIe lanes for variants without Gigabit Ethernet controller and PCIe
*2
switch
