Specifications

1.1

Feature List

Table 1 Feature Summary
Form Factor
Processor
Memory
Chipset
Audio
Ethernet
Graphics Options
Peripheral
Interfaces
BIOS
Power Management
Note
Some of the features mentioned in the above Feature Summary are optional. Check the article number of your module and compare it to the
option information list on page 8 of this user's guide to determine what options are available on your particular module.
Copyright © 2008 congatec AG
Based on COM Express™ standard pinout Type 2 (Basic size 95 x 125mm)
Intel Celeron M 600MHz with 512 kB L2 cache ULV (Ultra Low Voltage)
®
Intel Celeron M 373 ULV 1.0GHz, with 512 kB L2 cache (Ultra Low Voltage)
®
Intel Celeron M 370 1.5GHz, with 1 MB L2 cache
®
1 socket: SO-DIMM DDR2 up to 2 GB physical memory.
Graphics and Memory Controller Hub (GMCH) Intel
Intel I/O Controller Hub 82801FBM (ICH6M)
®
AC'97 Rev.2.3 compatible, HDA (High Definition Audio)/digital audio interface with support for multiple codecs
Gigabit Ethernet, Realtek RTL8111 (uses one x1 PCI Express Link)
Intel Graphics Media Accelerator 900 with max.224MByte Dynamic Video Memory Technology (DVMT 3.0) as well as Dual independent display
®
support.
• CRT Interface: 400 MHz RAMDAC
Resolutions up to 2048x1536 @ 70Hz (QXGA)
• Flat panel Interface (integrated)
2x25-112MHz LVDS Transmitter
Supports all 1x18, 2x18, 1x24, 2x24 bit TFT configurations (current chipset
revisions support 24Bit modes although not officially stated by Intel
Supports both conventional (FPDI) and non-conventional (LDI) color mappings
Automatic Panel Detection via EPI (Embedded Panel Interface based on
VESA EDID™ 1.3) Resolutions 640x480 up to up to 1400x1050 (SXGA)
Up to 1600x1200 (UXGA) for 82915GME
• 2x Serial ATA
®
• 3x x1 PCI Express Links (optionally, one additional x1 link if x16 link
®
(available only on 82915GME equipped variants) is not used)
• SDVO (the PCI Express Graphics x16 link available on 82915GME
equipped variants is shared with SDVO)
• 8x USB 2.0 (EHCI)
Based on AMIBIOS8 ® 1MByte Flash BIOS with congatec Embedded BIOS features
ACPI 2.0 compliant with battery support. Also supports Suspend to RAM (S3).
82910GMLE or 82915GME
®
• Motion Video Support
Up- and Downscaling
High definition content decode
H/W motion compensation
Subpicture support Dynamic bob and weave
) • AUX Output: 2 x Intel compliant SDVO ports (serial DVO)
®
200MPixel/sec each (shared with PEG x16 pins on 82915GME
equipped variants) Supports external DVI, TV and LVDS
transmitter
• PCI Bus Rev. 2.3
• 1x EIDE (UDMA-66/100)
• LPC Bus
• I²C Bus, Fast Mode (400 kHz) multimaster
