Com express type 6 revision 3.1 evaluation carrier board

4.5

PCIe Connectors

The conga-TEVAL3/COMe 3.1 provides:

• one x4 PCIe slot connector X9 (PCIe lanes 0–3)

• two x1 PCIe slot connectors X7, X8 (PCIe lanes 6 and 7)

• one M.2 key B socket connector X12 (PCIe lane 4)

• one M2. key E socket connector X16 (PCIe lane 5)

• one PEG x16 Gen4 slot connector X6 (PEG lanes 0–15)

The table below shows how the signals are routed to the connectors:

Table 16

PCIe Routing

PCIe Lane

PCIe 0, 1, 2, 3

PCIe 4

PCIe 5

PCIe 6

PCIe 7

Connector

X9 (PCIe x4 Slot)

X12 (M.2 key B)

X16 (M.2 key E)

X7 (PCIe x1 Slot)

X8 (PCIe x1 Slot)

TEVA31_m001

28/62
