SmartRelay 3 system (Manual)
Locker system with direct cabling
Power supply unit
(12-15V)
+
AC
1
AC -
The locker of the locker system opens when power is supplied to the locker
locking device. Normally, the contacts of the SmartOutput module are
open and the current does not flow through the contacts of the
SmartOutput module to the locker locking devices. When the contact on
the SmartOutput module is closed, the locker opens. Possible causes:
An authorised identification device is activated on the reader. The relay

contact of the SmartOutput module closes.
The button is actuated. The relay contact of the SmartOutput module

closes.
A remote opening of the SmartRelay is performed.

You can use the following cable types under the following conditions. (For
detailed wiring information, see
Number
1
Controller
2
A-
Reader
Out
K1
K2
-(1) (1)+ 1a
-(2) (2)+ 2a
-(3) (3)+ 3a
-(4) (4)+ 4a
3 3
-(5) (5)+ 5a
-(6) (6)+ 6a
-(7) (7)+ 7a
-(8) (8)+ 8a
Locker system SmartOutput module
Information on cabling [
Framework conditions Cable type
Cable length power
supply unit to controller
≤ 15 m (15 m outward
and 15 m return)
8. Setting up
2
A+
1b
2b
3b
4b
5b
6b
7b
8b
178] ).
}
F-YAY 2x2x0.6
