Simons Voss Technologies SmartRelay 3 Manual page 116

SmartRelay 3 system (Manual)
Signal timing
tpP
D0
D1
CLS
Bit 0
tCLS- tdL
Descrip-
Time
tion
Time
between
activation
t of the CLS
CLS-
signal and
first data
bit
Data bit
t pulse
dL
width
Time
between
t
pI
two bits
(idle time)
Signal
period
t
pP
(data rate
period)
tpP tpP
1 0 0
tpI
"Card is loaded"
"Data is being transmitted"
Min. Typ.
8 10
80 100
800 900
900 1000
10. SREL3 ADV in LSM
tpP tpP tpP
1 0 1
Max. Unit
12 ms
120 µs
1000 µs
1100 µs
116 / 189
tCLS+
