SmartRelay 3 system
14.2 Properties
14.2.1 Controller
(Manual)
SREL3.EXT.G2.W.WP
SmartOutput module
MOD.SOM8
Accessories
POWER.SUPPLY.2
SREL2.COVER1
SREL3.COVER.GY
SREL3.COVER.W
Housing
Material ABS plastic, UV-stable
Colour Same as RAL 9016 (traffic white)
Standard protec-
IP20
tion rating

Wiring to device

Power supply
(only one power supply must be connected)


Screw terminals

The max. current depends on the supply voltage and
the activity of the controller.
Reader for the SREL3 ADV system
(version with splash water protec-
tion)
SmartOutput module (standard
version)
Power supply unit (12 V
Vandalism protection housing
Vandalism protection frame for LED
reader, anthracite
Vandalism protection frame for LED
reader, white
Flush mounting
Surface mounting
V : 9 V – 32 V
IN DC DC
Power input: max. 3 W
Reverse voltage protection: yes
14. Technical specifications
162 / 189
, 500 mA)
DC
