Simons Voss Technologies SmartRelay 3 Manual page 155

SmartRelay 3 system
12.2 Battery replacement
Dispose of the batteries as per local and country-specific regulations.
(Manual)
4. Select the "TCP nodes" item.
5. Click on the Read button.
9 Locking device is read.
Battery level is displayed in the "State" section.
9
9 Battery level is displayed in the "State during last read-out" section in
the [State] tab in properties.
NOTE
Shorter battery life due to poor contact
Skin oil impairs contact between the battery and the battery holder.
1. Do not touch the contacts on new batteries with your hands when
replacing old ones.
2. Use clean cotton gloves free of fat or grease.
Controller disconnected from power supply.
ü
1. Press in the controller housing at the indicated point and lift the lid.
Housing is open.
9
12. Maintenance
155 / 189
