SmartRelay 3 system
14.2.2 Reader
(Manual)



Supported proto-

cols



Electrical spe-
See digital outputs
cifications
IMPORTANT
*) Undervoltage at the reader with PoE supply
When the controller is powered via PoE, a voltage converter reduces the
PoE supply voltage to 13V. This voltage is available for supplying the con-
nected readers and may not be sufficient for long cables or too small
cross-sections to ensure trouble-free operation of the reader (see also
formation on cabling [
1. Use an external power supply for the reader.
2. Use an external power supply for the controller, whose voltage
significantly exceeds 13 V
also increases the supply voltage for the reader and the voltage drop on
the line no longer has any effect.
3. Shorten the cable length.
4. Increase the cable cross-section.
Housing
Material ABS plastic, UV-stable
Colour Same as RAL 9016 (traffic white)
IP20
Standard protec-
IP65 with WP variant
tion rating
Vandalism-resistant housing available
Wiring to device Flush mounting
Power supply
Wiegand, 33 bit
Wiegand, 26 bit
Primion
Siemens Cerpass
Kaba Benzing
Gantner Legic
Isgus
178]
). Take one of the following actions:
}
to increase the internal supply voltage. This
DC
14. Technical specifications
166 / 189
