Simons Voss Technologies SmartRelay 3 Manual page 145

SmartRelay 3 system
10.15 Things to do
10.15.1 Initial programming via TCP/IP
(Manual)
11. Select the state of the input to be detected as "locked" by SmartSur-
veil.
12. Click on the OK button.
9 Window closes.
SmartSurveil is configured to monitor the SREL3 ADV system.
9
NOTE
SmartSurveil will only detect a door as locked if it has previously been de-
tected as closed.
NOTE
These settings apply to all SREL3 ADV systems in the linked LSM data-
base.Select the input that monitors whether a door is closed.
For details on SmartSurveil, please refer to the SmartSurveil manual.
In some use cases, the controller needs to be installed first and then
programme the address (pre-installed reader). It may no longer be
possible to reach the controller with a USB cable after installation.
Whatever happens, an IP address assigned to the controller and known to
LSM requires initial programming via TCP/IP.
This problem can be avoided if the controller is first programmed via a USB
cable separately from other components. During programming, a valid IP
address is issued and saved to the controller. The controller is then reset
but the IP address is retained.
Initial programming with USB cable and address assignment
Carry out initial programming as described in
NOTE
10. SREL3 ADV in LSM
145 / 189
Configuration [ 24] .
}
