SmartRelay 3 system
14.4.2 Reader
14.4.3 SREL3 LED/LR reader drilling template
(Manual)
IMPORTANT
The asterisk marks an optional drill hole. It is not required to fasten the
reader, but it can be used to feed the cable in the WP variant.
Only drill this hole if you wish to use the hole as a cable feed-through for
the WP variant.
*WP: Cable fixed with glue
Outer edge of the lid
*WP: No opening
100 mm
14. Technical specifications
186 / 189
