SmartRelay 3 system
10.4 Time budgets
(Manual)
IMPORTANT
Changing over the relay contact if power fails
The relays in the controller are not bi-stable. Consequently, permanent
power is required for switched mode. Relays are no longer supplied with
electricity if there is a power outage. In such cases, they switch to a power-
off state even without using an identification medium, depending on the
original position.
Connect external components in such a way that a power-off state

poses no risks.
NOTE
The flip-flop option is not available if the SREL3 ADV system is used with
SmartOutput modules.
LSM 3.4 SP1 or higher installed.
ü
Components connected to power.
ü
ü Components wired correctly (see
Controller has already been programmed.
ü
1. Double-click on the SmartRelay 3 entry in the matrix to open the set-
tings.
2. Change to the [Configuration/Data] tab.
3. Enable the Flip Flop checkbox.
4. Click on the Apply button.
5. Click on the Exit button.
6. Execute programming (see
Flip-flop mode is activated.
9
Time budgets are a convenient way to ensure regular identification media
updating in the virtual network. If a time budget is issued, which must be
uploaded to a gateway, users are forced to use their identification medium
on the gateway on a regular basis. During this process, not only is the time
budget uploaded, but other updates are also transmitted.
Identification media may become lost or stolen. Issuing a time budget
ensures that identification media are automatically no longer authorised on
the locking devices, because their time budget can no longer be uploaded
once rights are withdrawn. Issuing a time budget thus increases security in
the locking system.
wiring [ 58]
).
}
Programming [ 29]
).
}
10. SREL3 ADV in LSM
110 / 189
