SmartRelay 3 system
10.15.2 Different authorisations on transponders
(Manual)
In this case, external components do not need to be connected.
Resetting the controller
Reset the controller as described in
[ 33] .
}
Installing the controller
Install the controller in its final place of use. Connect the controller to the
other components and the power supply (see
Programming via TCP/IP
Execute programming via the previously assigned TCP/IP address (see
Programming [ 29]
).
}
The SREL3 ADV system is now ready for use.
A transponder with an integrated MIFARE chip is regarded as two different
identification media for both LSM and the SREL3 ADV system from a logic
viewpoint. You can make use of this characteristic and activate different
outputs on the controller and the SmartOutput modules using the same
transponder by assigning different authorisations to the MIFARE chip than
to the transponder.
ü Controller has already been programmed.
Components wired correctly (see
ü
ü Components connected to power.
ü Matrix open for the corresponding locking system.
1. Click on the New transponder button.
9 The "New transponder" window will open.
10. SREL3 ADV in LSM
Resetting controller with a USB cable
wiring [ 58]
}
wiring [ 58] ).
}
