SmartRelay 3 system (Manual)
-
+
1(1)
<
1(2)
2(1)
<
2(2)
+1
-
B1
A1
+2
-
B2
Controller
A2
+3
-
B3
A3
O4
O3
O2
O1
O+
I3
I2
I1
-
I+
Controller-fed reader with SmartOutput modules
The reader is connected as described before (see
the controller [ 58]
). The SmartOutput modules are also powered via a
}
power supply unit outside the cab. The SmartOutput modules' earth
system must be connected to the controller's earth system.
L
N
Power supply unit
+
-
L
N
Power supply unit
+
-
Drag cable
8. Setting up
91 / 189
+
Lift
electronics
-
-
+
-
Reader
B
A
Power supply through
