SmartRelay 3 system
10.5 Consequences in the event of a network failure
10.6 Signal settings
(Manual)
ü Controller has already been programmed.
Components wired correctly (see
ü
Components connected to power.
ü
1. Double-click on the SmartRelay 3 entry in the matrix to open the set-
tings.
2. Change to the [Configuration/Data] tab.
3. Enable the Ignore activation or expiry date checkbox.
4. Click on the Apply button.
5. Click on the Exit button.
6. Execute programming (see
If the network fails, only part of the information will still be transferred:
Time budgets and buffer-stored block IDs are still transmitted from the

controller to the identification media. The locking system continues to
function.
Block feedback signals are transmitted from the identification media to

the controller. The physical access list is also transmitted to the
controller in the case of cards. All information is buffered in the
controller. Once connection is re-established, the controller transmits
the stored information to LSM.
Authorisation changes are not edited in the virtual network.

Input events are not transmitted to the database and expire.

In some cases, an optical or audible feedback signal may not be wanted.
You can also change signal settings as you wish.
LSM 3.4 or higher installed.
ü
Controller has already been programmed.
ü
ü Components wired correctly (see
Components connected to power.
ü
1. Double-click on the SmartRelay 3 entry in the matrix to open the set-
tings.
2. Change to the [Configuration/Data] tab.
3. Click on the Extended configuration button.
The "Extended configuration" window will open.
9
wiring [ 58] ).
}
Programming [ 29] ).
}
wiring [ 58]
).
}
10. SREL3 ADV in LSM
