- Page 1 SmartRelay: SREL, SREL.ZK, SREL.ADV Published: December 2006...
-
Page 2: Table Of Contents
SmartRelay: SREL, SREL.ZK, SREL.ADV Content Important Information ..............4 Product Description ..............5 Before Ordering................6 Determine Which Version of the SmartRelay you need....6 Determine Which Accessories you need ........... 6 Dimension and Procure Power Supplies..........6 Determine the Installation Position............. 7 Additional Information:................. 7 Before Installation .................7... - Page 3 SmartRelay: SREL, SREL.ZK, SREL.ADV Content 7.11 Number of expansion modules ............16 7.12 Pulse length ..................16 7.13 Interface ....................17 7.14 Restricted range.................. 17 7.15 External Beeper/ External LED ............17 7.16 Log unauthorized accesses............... 18 Serial Interface ................19 Functional Description ...............
-
Page 4: Important Information
Do not charge, open or burn these batteries or heat them to more than 100 °C (212 °F). Installation of a SimonsVoss SmartRelay requires knowledge in the areas of door mechanics, door certifications, installation of electronics and the use of the SimonsVoss software. -
Page 5: Product Description
Inc. is not liable for the consequences of incorrect installation, such as blocked access to injured or endangered persons, property damage or other damages. If you will be storing the SmartRelay for more than one week, remove the backup battery. -
Page 6: Before Ordering
1. SmartRelay basic version: ordering code SREL This relay allows simple yes/no authorization for up to 8184 different transponders. 2. SmartRelay Plus version with access logging and time zones: ordering code SREL.ZK. Like the basic version, but with the capability of separately switching on access logging for the last 1024 accesses (for firmware version 4.0.01.15 and... -
Page 7: Determine The Installation Position
Verify the function of the SmartRelay with a transponder in the condition as received from the factory. If you are installing the SmartRelay in a flush socket device, remove the housing. If you are installing the SmartRelay on the wall, you can use the bottom plate as a template for drilling. -
Page 8: Installation Of The Backup Battery
Installation of the Backup battery Backup Batterie nur einsetzen, wenn das Smart Relais mit Insert the battery only if you will be operating the SmartRelay with Netzteil betrieben wird, bei Betrieb mit SREL.BAT diese the power supply. Do not insert this battery if you will be operating with the SREL.BAT! -
Page 9: Installation
Switch on the supply voltage (if necessary, insert the plug or connect the battery). Verify the function of the SmartRelay with a transponder in the condition as received from the factory. Program the SmartRelay with the SimonsVoss software (we recommend software version LDB.EXE 1.40 or later). -
Page 10: Connection Assignments
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 10 Connection Assignments SREL and SREL.ZK + / ~ Power Netzteil - / ~ Battery Batterie SREL.BAT Antenna Relais Externe Ein- external inputs Ausgänge and outputs Brown White + / ~ Externe Antenne External antenna... -
Page 11: Srel.adv
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 11 SREL.ADV Description of the SREL, SREL.ZK and SREL.ADV Connection Symbol Name Description Power supply + / ~ If connecting a direct current (5 to 24 VDC) source, use the positive pole, otherwise use one of the two alternating current... -
Page 12: Programming And Configuration
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 12 Programming and Configuration When you choose SmartRelay as the locking type in the SimonsVoss software (Version 1.40 and later), you have the following configuration options:... -
Page 13: Access Control
The SmartRelay receives a transponder signal and then sends it again, amplified. You can use the SmartRelay in this function in order to link a way through larger radio paths. The distance to another SmartRelay can be up to 6.5 ft. (2 m). -
Page 14: Omron
This means that you can also use the SimonsVoss transponder in systems from other companies. If you would like the SmartRelay to transmit the transponder data to such an external system, and for the SmartRelay to send a remote opening command to a cylinder when released by this external system, then select this option, both on the Smart Relay and on the cylinder. -
Page 15: 7.7.1 The Smartrelay In Omron Mode
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 15 7.7.1 The SmartRelay in OMRON Mode Authorized? Access control system Externes Zutrittskontroll- oder External access control or Zeiterfassungssystem time recording system Release relay Freischalt Relais + 5..12VDC Pull up resistors Pull Up Widerstände Clock / D1... -
Page 16: No Acoustic Programmer Acknowledge
This is where you specify which external unit is connected. In Flip Flop mode, the SmartRelay generates a continuous signal when switched if there is an external LED connected; if a beeper is connected, it briefly acknowledges each change of state with a sound signal. -
Page 17: Interface
7.14 Restricted range If you select this option, the reader range from the transponder > SmartRelay is restricted from approximately 4.9 ft (1.5 m) down to1.3 ft ( 0.4 m). For example, you can use this option if there are several SmartRelays close to one another and individual transponders are authorized for several SmartRelays. -
Page 18: Log Unauthorized Accesses
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 18 If the current for the external component is larger than 10 mA, then this component must be fed by an external power supply. In this case, the connection should be made as follows: Ext. Netzteil... -
Page 19: Serial Interface
Serial Interface Functional Description In order to use a SmartRelay as a card reader in an external access control or time recording system, both the hardware (cable and signal level) and the data formats must correspond exactly to those of the card reader. Only then can the external system understand and evaluate the data from the SimonsVoss transponders. -
Page 20: Kaba Benzing, Siemens, Gantner Legic, Primion, Isgus Interface
Maintenance Battery Warning and Battery Replacement if you are using the SREL.BAT battery In case the battery capacity is no longer sufficient, a SmartRelay can issue a battery warning as follows: SREL, SREL.ZK, SREL.ADV Internal LED blinks 8 times each time you operate the transponder and before the relay is switched. -
Page 21: Backup Battery
If the SmartRelay needs the backup battery often because of frequent power failures, you should replace this battery routinely. If you operate the SmartRelay with a battery (SREL.BAT), you are not permitted to use the backup battery. -
Page 22: 10.0 Data Sheet
SmartRelay: SREL, SREL.ZK, SREL.ADV Page 22 10.0 Data sheet Housing made of black plastic: 72 x 57 x 25.5 mm (approximately 2.8 x 2.2 x 1.0 inches) Dimensions [LxWxH Degree of protection IP 20 (NEMA1), not tested for outside use Temperature Operation at: -31°F to +131°F...
