SREL1+2
Manual
17.09.2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartRelay SREL Series and is the answer not in the manual?

Questions and answers

Related Manuals for Simons Voss Technologies SmartRelay SREL Series

Summary of Contents for Simons Voss Technologies SmartRelay SREL Series

  • Page 1 SREL1+2 Manual 17.09.2019...

  • Page 2: Table Of Contents

    Content SREL1+2 (Manual) 2 / 38 Content Intended use .............................. 4 Safety instructions ............................  5 General ................................ 8 Versions ................................ 8 Accessories ...............................  10 Power supply.............................. 11 Determining installation position ...................... 12 More information............................. 12 Initial operation............................ 13 Connections...............................  14 SmartRelay (SREL) ............................ 14 SmartRelay Advanced (SREL.ADV).....................  15 SmartRelay2 (SREL2) .......................... 17 Notes on SREL connection ........................
  • Page 3 Content SREL1+2 (Manual) 3 / 38 Help and other information .........................  36...

  • Page 4: Intended Use

    1. Intended use SREL1+2 (Manual) 4 / 38 1 Intended use SimonsVoss SmartRelay is an electronic switch which can be activated with suitable ID media such as transponders . SmartRelay administration varies depending on the SmartRelay in question: ADMINISTRATION PROGRAMMING LSM Basic, Business or SMART.CD Professional...

  • Page 5: Safety Instructions

    2. Safety instructions SREL1+2 (Manual) 5 / 38 2 Safety instructions WARNING Access through a door may be denied if locking devices are installed or pro- grammed incorrectly. SimonsVoss Technologies GmbH is not liable for consequences of incorrect installation, such as denied access to injured persons, physical damage or any other losses.
  • Page 6 2. Safety instructions SREL1+2 (Manual) 6 / 38 IMPORTANT You must perform a functional test without fail after installing SmartRelay or replacing its batteries. IMPORTANT We reserve the right to make modifications or further technical develop- ments. IMPORTANT This documentation has been compiled based on the best knowledge available to us.
  • Page 7 2. Safety instructions SREL1+2 (Manual) 7 / 38 IMPORTANT Do not touch the contacts on the new batteries with your hands when re- placing the old ones. Use clean gloves free of fat or grease to handle the battery. IMPORTANT Only use batteries which have been approved by SimonsVoss.

  • Page 8: General

    3. General SREL1+2 (Manual) 8 / 38 3 General 3.1 Versions SmartRelays are available in an extensive variety of versions for different product lines. Carefully check which SmartRelay is the right one for your use before placing an order. SREL (black) SREL2 (white) Basic version of SmartRelay SREL...
  • Page 9 3. General SREL1+2 (Manual) 9 / 38 Support for MIFARE & Desfire cards Connection options for ex- ternal card readers SREL SREL SREL SREL .ZK.G2 .G2.W .ZK.G2.W Authorised for up to 8,184 transponders Authorised for up to 64,000 transponders Access control Extended connection options Support for MIFARE &...

  • Page 10: Accessories

    3. General SREL1+2 (Manual) 10 / 38 Connection for external modules via a three-wire bus.  Connection to an external antenna.  Connections for serial ports to external time-and-attendance  terminals or access control readers. Connection for external LED or buzzer. ...

  • Page 11: Power Supply

    3. General SREL1+2 (Manual) 11 / 38 SREL2.COVER1 Accessories for SmartRelay 3063 (G2) SREL2.ZK.MH.G2 SREL2.G2.W SREL2.ZK.G2.W SREL.AV WNM.LNI.SREL2.G2 SC.M.I.G2 SC.M.E.G2.W SREL2.COVER1 SC.M.E.G2.W (Mifare smart card, external, G2 white)  A maximum of two external card readers (SC.M.E.G2.W) and an internal card reader (SC.M.I.G2) can be connected to a SREL2.ZK.MH.G2.W or SREL2.ZK.MH.G2.W.WP.

  • Page 12: Determining Installation Position

    3. General SREL1+2 (Manual) 12 / 38 IMPORTANT Do not use switched-mode power supplies near SmartRelays. 3.4 Determining installation position The transponder transmission range for SmartRelay (read range) is a max. of 1.5 m, but may be reduced in environments containing metals, especially in magnetic fields or where aluminium is present.

  • Page 13: Initial Operation

    4. Initial operation SREL1+2 (Manual) 13 / 38 4 Initial operation Check 1. Unpack SmartRelay and check for any damage. 2. Connect SmartRelay to a power supply or a battery. 3. Activate the SmartRelay with a transponder and test whether the SmartRelay responds to activation in some way or other.

  • Page 14: Connections

    5. Connections SREL1+2 (Manual) 14 / 38 5 Connections 5.1 SmartRelay (SREL) Power supply unit Battery Relay NAME SYMBOL DESCRIPTION Either positive terminal when connected to a direct current (5 to 24 VDC) or one of the Power supply unit + two alternative current connections (12 V AC) Either minus terminal when connected to a...

  • Page 15: Smartrelay Advanced (Srel.adv)

    5. Connections SREL1+2 (Manual) 15 / 38 Normally open contact in the relay NO relay changeover contact. This contact is closed against Relay COM when not connected 5.2 SmartRelay Advanced (SREL.ADV) External inputs and outputs Power supply External antenna unit SREL.AV SREL.BAT battery Relay...
  • Page 16 5. Connections SREL1+2 (Manual) 16 / 38 Either minus terminal when connected to a Power supply unit - direct current (5 to 24 V DC) or the second alternative current connections (12 V AC) Connector for a battery when operated Battery without a power supply unit; order code for battery, including SREL.BAT connector Normally closed contact in the relay Relay NC...

  • Page 17: Smartrelay2 (Srel2)

    5. Connections SREL1+2 (Manual) 17 / 38 5.3 SmartRelay2 (SREL2) Connection for LNI Connection for card readers External antennas Functions connections Power supply Relay NAME SYMBOL DESCRIPTION Power supply unit + Direct current 9 to 24 V DC Power supply unit - Direct current 9 to 24 V DC Common contact in the relay.

  • Page 18: Notes On Srel Connection

    5. Connections SREL1+2 (Manual) 18 / 38 Functions con- Input ext. Trigger input (3-24 V DC nection 1 ext. contact must be isolated) Functions con- Omron data / Wiegand DO nection 2 Omron CLK / Wiegand D1 Functions con- LED / buzzer (external) nection 3 Card reader line link SimonsVoss bus –...

  • Page 19: External Signalling

    5. Connections SREL1+2 (Manual) 19 / 38 5.4.1 External signalling Possible resistance to power limitation. The V+ output supplies max. 10 mA at 3 V DC Buzzer or LED...
  • Page 20 5. Connections SREL1+2 (Manual) 20 / 38 External power supply unit Possible resistance to power limitation. The V+ output withstands max. 50 mA Max. Buzzer or LED...

  • Page 21: Omron

    5. Connections SREL1+2 (Manual) 21 / 38 5.4.2 OMRON External access control or time-and- attendance system Activation relay Pull-up resistances...

  • Page 22: Wiegand Interface

    5. Connections SREL1+2 (Manual) 22 / 38 5.4.3 Wiegand interface External access control or time-and- attendance system Pull-up resistances...

  • Page 23: Kaba Benzing, Siemens, Gantner Legic, Primion And Isgus Interface

    5. Connections SREL1+2 (Manual) 23 / 38 5.4.4 Kaba Benzing, Siemens, Gantner LEGIC, Primion and ISGUS interface External access control or time-and- attendance system Pull-up resistors 5.5 Notes on SREL2 connection SREL2.G2 with three card interfaces It is possible to operate the SREL2 with a total of 3 card interfaces at the same time (1 x internal and 2 x external).

  • Page 24: Configurations In The Software

    6. Configurations in the software SREL1+2 (Manual) 24 / 38 6 Configurations in the software SmartRelays are very specific due to their hardware and can therefore only be operated in environments designated for them. Item order code Protocol generation Software SREL G1: Type G1 or G2 + G1 SREL.ZK...
  • Page 25 6. Configurations in the software SREL1+2 (Manual) 25 / 38 Replacement transponders can overwrite their corresponding original transponders. The original transponder is blocked once the replacement transponder is used for the first time. Flip-flop  Pulse mode (default setting) is switched off and the pulse duration no longer plays a role.
  • Page 26 6. Configurations in the software SREL1+2 (Manual) 26 / 38 This is where you indicate the number of seconds for the duration of switch pulse. The value can be set at 0.1 to 25.5 seconds. If you enter 3 seconds, for example, an electric strike is released for 3 seconds before it locks again.

  • Page 27: Locking Device Properties: Configuration/Data: Smartrelay (G2)

    6. Configurations in the software SREL1+2 (Manual) 27 / 38 Internal/external antennas  For SREL.ADV only Auto-detection  If an external antenna is connected, this is the one which is used. SmartRelay switches off the internal antenna in such cases. If no external antenna is connected (standard case), SmartRelay functions with the internal antenna.
  • Page 28 6. Configurations in the software SREL1+2 (Manual) 28 / 38 Pulse mode (default setting) is switched off and the pulse duration no longer plays a role. When flip-flop mode is activated, SmartRelay changes its status from on to off or vice versa each time it is activated using a transponder.

  • Page 29: Mobilekey

    6. Configurations in the software SREL1+2 (Manual) 29 / 38 You can enter the type of card reader here which the SmartRelay is to simulate for operation as a serial interface. The following options are available: Wiegand, 33 bit  Wiegand, 26 bit ...

  • Page 30: Signalling

    7. Signalling SREL1+2 (Manual) 30 / 38 7 Signalling SREL LED lights up or flashes green: ID medium is authorised and the SREL  activates. No response from the LED: ID medium rejected or not recognised.  SREL2 LED lights up or flashes blue: ID medium is authorised and the SREL2 ...

  • Page 31: Maintenance

    8. Maintenance SREL1+2 (Manual) 31 / 38 8 Maintenance 8.1 Battery warning and battery replacement when SREL.BAT is used A SmartRelay can emit a battery warning as follows when the battery capacity is depleted: SREL, SREL.ZK and SREL.ADV  Inside LED flashes 8x each time a transponder is used and before ...

  • Page 32: Technical Specifications

    9. Technical specifications SREL1+2 (Manual) 32 / 38 9 Technical specifications Radio emissions -4.7 dBµA/m (10 m dis- 24.45 kHz - 24.47 kHz tance) 13.558 MHz - 13.564 4.1 dBµA/m (10 m dis- RFID tance, V=13.2) SRD (WaveNet) (de- 868.000 MHz) - <25 mW ERP pending on equipment) 868.600 MHz...

  • Page 33: Technical Specifications For Srel2

    9. Technical specifications SREL1+2 (Manual) 33 / 38 9.2 Technical specifications for SREL2 Housing made of white plastic: Di- mensions LxWxH Base plate semi- About 78 x 78 x 19 mm transparent IP20, not tested for outside use Protection rating WP version: IP65 When operating: -22°C to 55°C Temperature...

  • Page 34: White Srel2 Drilling Template

    9. Technical specifications SREL1+2 (Manual) 34 / 38 9.3 White SREL2 drilling template Specifications in mm...

  • Page 35: Declaration Of Conformity

    10. Declaration of conformity SREL1+2 (Manual) 35 / 38 10 Declaration of conformity The company SimonsVoss Technologies GmbH hereby declares that article SmartRelais complies with the following guidelines: 2014/53/EU "Radio equipment"  2014/30/EU "EMC"  2011/65/EU "RoHS"  2012/19/EU "WEEE" ...
  • Page 36 11. Help and other information SREL1+2 (Manual) 36 / 38 11 Help and other information Information material/documents You will find detailed information on operation and configuration and other documents under Informative material/Documents in the Download https://www.simons-voss.com/en/ section on the SimonsVoss website ( downloads/documents.html Declarations of conformity You will find declarations of conformity for this product in the Certificate...
  • Page 37 11. Help and other information SREL1+2 (Manual) 37 / 38 SimonsVoss Technologies GmbH Feringastrasse 4 85774 Unterföhring Germany...
  • Page 38 This is SimonsVoss SimonsVoss is a technology leader in digital locking systems. The pioneer in wirelessly controlled, cable-free locking technology delivers system solutions with an extensive product range for SOHOs, SMEs, major companies and public institutions. SimonsVoss locking systems unite intelligent functions, optimum quality and award-winning German-made design.
