SmartRelay 3 system
10.7.1.1 Wiegand26 (standard format)
(Manual)
Canteen billing systems

This allows to control all relevant systems with just one identification
medium, e.g.:
Building automation systems

Access control

Time-and-attendance

Canteen billing

The serial interface supports different signal and data format variants for
the different manufacturers:
Wiegand26 (standard format)

Wiegand33 (for PRIMION connections)

OMRON Primion

OMRON Siemens-CerPass

OMRON Gantner-Legic

OMRON Dormakaba

OMRON Isgus

Signal description
A Wiegand interface uses the following standardised signals:
Signal Meaning
D0 Data 0
D1 Data 1
Card load-
CLS
ing signal
All outputs are open-drain. A pull-up resistor (1kΩ to 10kΩ type) and the
positive power supply (3 V
The signals are "Active low".
SREL.ADV
Explana-
connec-
tion
tion
F1 ("D0")
F2 ("D1")
Optionally F3 ("LED/
configur- buzzer/in-
able put1")
to 24 V ) must be provided for signal lines.
DC DC
10. SREL3 ADV in LSM
115 / 189
SREL AX
SREL3
Classic
ADV con-
connec-
nection
tion
O1 Output 1
O2 Output 2
Not avail-
O3
able
