SmartRelay 3 system (Manual)
NOTE
Initial programming via USB
The controller can be addressed via TCP/IP. However, no IP address is con-
figured in storage mode. That is why initial programming, during which an IP
address is assigned, must be carried out with a USB connection.
Components connected to power.
ü
ü Controller connected to computer with USB cable.
ü Reader connected to the controller (see
LSM installed and launched as administrator.
ü
ü System requirements met.
ü Communication nodes set up (VN Host and CommNode; see LSM
manual).
1. Create a new G2 locking system.
2. Click on the ... button to open the locking system settings.
3. Change to the [G2 card management] tab.
4. Open the ▼ Card type drop-down menu.
5. Select your card type.
6. Open the ▼ Configuration drop-down menu.
7. Select a configuration.
NOTE
Suitable configurations
AV configurations are the only suitable ones for use in a locking system
with an SREL3 ADV system.
8. Click on the Apply button.
9. Click on the Exit button.
Matrix screen is visible again.
9
10. Create a new G2 Smart Relay 3 locking device.
11. Double-click on the SmartRelay 3 entry in the matrix to open the set-
tings.
12. Select the [IP settings] tab (see
on IP settings).
13. Enter an IPv4 address.
14. Enter an IPv4 subnet mask.
15. Open the ▼ Communication nodes drop-down menu.
wiring [ 58]
).
}
Establishing IP settings [
8. Setting up
